HST-2002D Automatic Furnace Infrared Carbon and Sulfur Analyzer

HST-2002D Automatic Furnace Infrared Carbon and Sulfur Analyzer

1. Applications:

This instrument is the first of a new generation of high-tech carbon and sulfur analysis instruments, for carbon and sulfur content determination of steel, low alloy steel, stainless steel and other materials. The instrument uses a high-frequency arc ignition heating combustion sample technology, the infrared absorption method to test carbon and sulfur content of the sample. It has a good detection accuracy and high stability, high reliability.

2. Functions and Features

1. Adopt imported infrared detector with low noise, high sensitivity, high stability.

2.Modular linear power, machine reliability, appearance.

3. Double carbon pool,disulfiram pool upgrades.

4. Electronic balance automatically online, no quantitative sample.

5. Full Chinese operation interface, convenient operation, easy to master.

6. Software functions, provide the file help, system monitoring, channel selection, mathematical statistics, results correction, breakpoint correction, more than forty functions.

7. Dynamic display the data and carbon-sulfur release curve of analysis process.

8. Measurement of wide linear range, and can be extended.

9. Imported electromagnetic valve,improve the reliability of gas system.

10. High frequency plasma non-contact ignition, automatic tracking the samples.

11. Energy-saving, materials saving, high-speed accurate.

3. Technical Specifications

1.Measuring range:

Carbon: ω(C)0.00050%—10.0000%( can be expanded to 99.9999%)

Sulfur: ω(S)0.00005%—0.35000%( can be expanded to 99.9999%)

2.Minimum reading: 0.00001

3. Analytical error: Carbon better than GB/T223.69—1997 Standard

4. Sulfur better than B/T223.68—1997 Standard

5. Analysis time: 25—60 can be adjusted, usually at 35 seconds.

6. Electronic balance: Weighing range: 0—100g

7. Reading accuracy: 0.001g(can be equipped millointh balance)

8. Work environment: indoor temperature: 10-30℃

9. Relative humidity: less than 10-30℃

10. Power: requires good grounding Voltage AC220V±5% Frequency 50Hz±2%

11.Channel settings: Carbon 10 channels, sulfur 10 channels

12.Sampling speed: 24times/second A/D Switching frequency: 120Hz
