Model

HBS-3000

Type

Digital Brinell

Testing range

8~650 HBW (hardmetals steel ball)

Brinell›hardness›test›(N)

612.5, 980, 1225, 1837.5, 2450, 4900, 7350, 9800, 14700, 29400

Load›control

Automatic

Magnification›of›microscope›x

20x for reading microscope

Max.›height›of›specimens›(mm)

220

Max.›depth›of›specimens›(mm)

135

Power

AC220V, 50/60Hz

Dimension›(DxWxH)›(mm)

550 x 236 x 753

Net›weight›(kg)

130

Packing List

Indenter

Steel ball indenter í2.5mmx1 í5mmx1 í10mmx1

Testing›table

Big / small /V, 1 for each

Hardness››block

HBW 3000/10 150~250 x 1, HBW 1000/10 75~125 x 1, HBW 187.5/2.5 150~250 x 1

Operation›manual

1

Reading›microscope

20x x 1

Micrometer›eyepiece

1
