MOPAO3s Double Discs Automatic Polishing Grinding Machine
- 1000 per Month
- T/T Credit Card
You May Like
-
MoPao300SE 300mm diameter discs Laboratory Compact Metallographic Grinding Polishing Machine
-
HCW250 Metallographic Consumables /carborundum grinding wheel/metallurgical cutoff wheel
-
JSZ7 Trinocular Continuous Zoom Stereomicroscope
-
JSZ5 Binocular zoom stereo microscope for industry
-
MoPao260E Double-disc Desktop Metallographic Grinding and Polishing Machine With Cooling System
-
MoPao3S Metallographic Specimen Automatic Grinding and Polishing Machine With Liquid Cooling Device And Scour Nozzle
Product Description
MoPao 3S Automatic Metallographic Specimen Grinding Polishing Machine is Touch Screen
Digital Display, Double Discs, Desktop Type.
It is a multi-purpose machine, one machine to achieve the metallographic specimen roughing
grinding, precision grinding and polishing the entire process.
It is the enterprises and research institutes ideal device.
2.Technical Parameters:
|
Model |
MoPao 3S |
|
Disc Diameter |
250 mm |
|
Disc Rotating Speed |
50~1000 r/min (Stepless Speed) And 150 r/min, 300 r/min (Two-step Constant Speed) |
|
Grinding Polishing Head Rotating Speed |
5 ~ 150 r/min (Stepless Speed) |
|
QTY Of Specimen Preparation |
4 PCS |
|
Specimen Force |
5 ~ 60N, Manual Pressure |
|
Time Of Specimen Preparation |
0 ~ 9999 s |
|
Specimen Diameter |
Φ30 mm (Or Customized Φ22 mm or Φ45 mm) |
|
Supply Power |
Single Phase, AC 220V, 50Hz, 870W |
|
Overall Dimensions |
980*920*470 mm |
|
N.W. / G.W. |
55 KG / 71 KG |
