HST ZXQ-1DA Fully-automic Metallographic
Specimen Mounting Press
1. Application:
Electric pressurized water-cooled type, with intelligent temperature control, timing setting and automatic water cooling functions, is suitable for the inlay of thermosetting and thermoplastic metallographic samples. The performance of this machine is superior to domestic similar products, and it is an ideal equipment for metallographic material analysis. With human-machine interface and PLC control, the steel mold sleeve can be replaced according to the actual situation, the appropriate sample preparation specification can be selected, and the sample inlay can be automatically completed by programming control.
2. Main specifications:
|
Model |
ZXQ-1DA |
|
Diameter of specimen |
Ø25mm, Ø30mm, Ø40mm,Ø50mm |
|
Cooling Type |
Water Cooling |
|
Power (W) |
1100W |
|
Mounting quantity per time |
1 |
|
Moulding temperature |
200℃ |
|
Cooling time(min) |
1~99 min |
|
Net weight(Kg) |
45Kg |
|
Power supply |
AC220V, 50Hz |
|
Dimension |
700mm×380mm×500mm |
CE certificate: Metallographic Lab Euqipment HST model
