Home > Products > Hydraulic Universal Testing Machine > WAW Hydraulic 2000KN 200ton universal testing machine
WAW Hydraulic 2000KN 200ton universal testing machine
- 1000 per Month
- T/T Credit Card
- WAW-1000D 1000kN Servo Hydraulic Universal Testing Machine
- WAW- D 300kN 600kN 1000KN 1500kN 2000kN Computer Automatic Hydraulic Universal Testing Machine
- WAW-1000D UTM Price Metal Steel Tensile Test Machine/servo universal tensile testing equipment
- WAW-D 300kN,600kN,1000kN,2000kN Hydraulic Power tensile compression universal testing machine/automatic universal tester
- HST WAW-1000 WAW-2000 1000KN 2000KN computer controlled hydraulic servo universal testing machine
- WAW Computerized Hydraulic Universal Testing Machine+Steel Tensile Testing Machine Price+Engineering Lab Equipment
Product Description
100kn Hydraulic Universal Testing Equipment, Testing Bench
1. Application
Factory Steel Rebar Steel Strip Steel Sheet Tensile Test Equipment for sale is suitable for tension,
compression, bending, shearing, peeling, tearing and other tests by adding different test fixture for metal and nonmetal materials. It is widely used in inspection department, engineering area, laboratories, universities and institutes for material properties research and quality control.
2. Standards
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
Model |
WAW-100D |
WAW-200D WAW-300D |
WAW-600D |
WAW-1000D/E |
WAW-1200E |
WAW-2000E |
|||
Control Way |
Constant stress uniform deformation constant displacement three closed loop control and program control dealing |
||||||||
Number of Screw drivers |
4 |
||||||||
Max. Load(KN) |
100 |
200 /300 |
600 |
1000 |
1200 |
2000 |
|||
Load Accuracy |
≤± 1%/ ≤± 0.5% |
||||||||
Load Range |
2%~100%FS |
||||||||
Load Resolution |
1/300000 |
||||||||
Deformation Measurement Range |
2%~100%FS |
||||||||
Deformation Accuracy |
≤± 1% |
||||||||
Displacement Resolution |
0.01mm |
||||||||
Testing speeds (mm/min) |
0.1~118 |
0.1~123 |
0.1~123 |
0.1~70 |
0.1~70 |
0.1~70 |
|||
Adjustable crosshead speed(mm/min) |
450 |
450 |
350 |
350 |
320 |
320 |
|||
Displacement Error |
≤±0.5% |
||||||||
Max. Piston Stroke(mm) |
200 |
200 |
200 |
200/250 |
250 |
250 |
|||
Max. Tension Test Space (mm) |
780 |
780 |
900 |
950/980 |
930 |
1250 |
|||
Max. Compression Test Space |
550 |
550 |
650 |
700 |
640 |
850 |
|||
Column Effective Spacing(mm) |
485 |
485 |
500 |
560/580 |
610 |
800 |
|||
Clamping Method |
Hydraulic Automatic Clamp |
||||||||
Flat Specimen Clamping Width(mm) |
80*80 |
80*80 |
90*90 |
100*100 |
120*110 |
150*120 |
|||
Compression Plate Size |
Φ 160mm |
||||||||
Bending Roller Distance |
450mm |
||||||||
Width Of Bending Rollers |
120mm |
||||||||
Power Supply |
3-phase, AC380V, 50Hz (Can Be Customized) |
