HSTAuto Power Computer Tensile Testing Machine Automatic Servo Control Tester For Steel Bars with CE certificate
Specifications
NO. |
Items |
Model |
WDW-10E |
WDW-20E |
WDW-30E |
WDW-50E |
WDW-100E |
1 |
Host |
Structure |
column and 2 Ball Screw |
||||
Max. Load(kN) |
10 |
20 |
30 |
50 |
100 |
||
Tensile space(mm) |
670 |
770 |
650 |
||||
Compression space(mm) |
900 |
1000 |
1000 |
||||
Effective test width |
450 |
450 |
550 |
||||
size(mm) |
850 x 590 x 1750 |
840 x 570 x 1850 |
950x660x2000 |
||||
Host Weight (kG) |
370 |
420 |
680 |
||||
Power Supply |
220V/50-60Hz |
||||||
2 |
Control System |
Controller |
24 bit AD, external controller |
||||
communication mode |
USB 2.0 |
||||||
Test software |
HKTest |
||||||
Hand control box |
320x240 Display Sscreen,8 key control |
||||||
3 |
Process Specifications |
Servo motor |
TAIWAN "TECO" |
||||
Speed(mm/min) |
0.01-1000 |
0.01-500 |
|||||
Displacement resolution |
0.4 pm |
0.2 pm |
|||||
4 |
Test Specifications |
Load cell |
USA(max load): one can add more load cell |
||||
Load accuracy |
Class 0.5, EN 10002-2 Grade0.5, ISO75001-1 Class 0.5, BS 1610 Class 0.5, ASTM E4, and JIS B7721 Class 0.5 |
||||||
Measuring range |
0.2%~100% |
||||||
5 |
Safety Protection |
strong electric drive system |
24V voltage control, with over current overloading protection function |
||||
Position limit switch |
Upper and lower lights |
||||||
Power |
Power light,leak current protection device |
||||||
Automatic protection |
Overload 10%, automatic protection |
||||||
Position limit protection |
Hall switch |
||||||
6 |
Other Configuration |
Equipment level adjusting device |
φ80mm vibration-absorptive cushioning iron |
||||
Hand control box fixing device |
Standard |
||||||
Note:Extra wide and/or extra height frames are available.Power supply system is completely customizable.Tensile space, test width, and speed is completely customizable. | |||||||
