KS 400-3015 horizontal type digital used profile projector
Specifications:
Model |
PH400-3015 |
PH400-3020 |
Code# |
512-401 |
512-411 |
Metal Stage Size |
408 x 126mm |
|
Stage Travel: X and Y-axis |
300 x 150mm |
|
Stage Travel:Y-axis |
75mm (for focusing) |
|
X and Z Linear Resolution |
0.0005 mm |
|
Sway Range |
±15° |
|
Accuracy |
≤3+L/200(um) |
|
Screen |
Diameter :Ø425mm,Effective Range ≥ Ø400(with “* ” Reticle) |
|
Rotary Range: 0~360° ; Resolution Rotary Indicator: 1’ or 0.01° | ||
Digital Readout |
DP 300 (561-301) Multifunctional Data Processing System |
|
Illumination |
Contour illumination:24v/150w (halogen Lamp ) |
|
Surface illumination:21v/150w (Optical Fiber) | ||
Power Supply |
AC110V/60Hz; 220V/50Hz, 650W |
|
Dimension (D×W×H) |
1160 x 600 x 960mm |
|
Packing Dimension (L×W×H) |
1300 x 880 x 1250mm |
|
Gross/Net Weight |
200/160Kg |
|
ACCESSORIES:
