TSZ-30 30KN Strain Controlled Soil Triaxial Testing Machine
1. Application:
TSZ-30 30KN Strain Controlled Soil Triaxial Testing Machine used to determine the strength and
deformation characteristics of the soil specimen under the static axial load.
It can perform unconsolidated-undrained shear test (UU), consolidated-undrained shear test (CU)
and consolidated-drained shear test (CD).
With high confining pressure, compact structure, simple operation, it does not need air-compressor
and nitrogen cylinder. It can meet test requirements for civil engineering projects such as large
buildings and dam construction etc.
2. Main Specifications:
|
Model |
TSZ-30 |
|
Specimen Size |
Φ 39.1mm x 80mm; Φ 61.8mm x 125mm |
|
Vertical Capacity |
30 KN |
|
Maximum Capacity |
30 KN |
|
Strain Rate |
0.0024-4.5 mm/min Mechanical Speed 16 Files |
|
Worktable Trip |
0-90 mm |
|
Confining Pressure:(σ3) |
0-2 MPa Digital Control and LCD Display |
|
Back Pressure:(σb) |
0-0.8 Mpa Digital Control and LCD Display |
|
Pore Pressure:(u) |
0-2 Mpa |
|
Volume Deformation |
0-50 ml, Min. Division:0.1 ml |
3. The Packing Way Of Our Export Machines:
4. The Realistic Pictures Of Our Factory:
5. Our Process Of Foreign Trade:
6. Our company can also produce the customized testing machines as clients' requirements.
You can contact me as the below information.
