Computer Control Instrumented (oscilloscope) Impact Tester Equipment Impact Tester Testing Machine
1. Brief introduction:
The machine is designed in accordance with ISO14556: 2000 "Steeel-charpy V-notch pendnlum impact test-Instvumented test method"; GB/T19748-2005 "Metal Charpy V-notch pendulum impact test instrumentation test method"; GB/T3808-2002 Developed relevant requirements in "Inspection of Pendulum Impact Tester".
By testing the impact force value, collecting and analyzing the impact process data, and drawing the energy change curve, the physics meaning and explanation are given at different stages of material fracture, which provides detailed and accurate data for studying and analyzing the behavior of the material fracture process.
2. Standard:
2.1.GB/T19748-2005 "Steel Charpy V-notch pendulum impact test (instrumentation) method"
2.2.ISO 14556: 2000 (E) "Steel-Charpy V-notch bending impact test-instrumental test method"
2.3.ASTM E23 "Steel Charpy V-notched pendulum impact test instrumentation method"
2.4.GB/T3808-2002 "Pendulum Impact Test Machine",
2.5.JJG145 "Verification Regulation of Pendulum Impact Tester"
3. Main Technical Specifications:
|
Model |
JBW-150H |
JBW-300H |
JBW-500H |
|
Control type |
Computer control |
||
|
Max energy |
150J |
300J |
500 |
|
Impact speed |
5.24m/s |
5.4m/s |
|
|
Pendulum pre-lift angle |
150° |
||
|
Angle accuracy |
±0.1° |
||
|
Specimen support span |
40+0.2mm |
||
|
Support jaw fillet |
R1.0~1.5mm |
||
|
Impact blade |
Izod impact blade,tensile impact blade,R2,R8 |
||
|
Impact knife angle |
30° |
||
|
Impact blade thickness |
16mm |
||
|
Distance from pendulum center to impact point |
750mm |
||
|
Standard sample size |
10×10(7.5 or 5)×55mm |
||
|
Load cell accuracy |
≤±1%FS |
||
|
Impact pendulum configuration |
150J pendulum |
150J and 300J pendulum |
250J and 500J pendulum |
|
Power supply |
380V/50Hz /Three-phase four-wire |
||
|
|
