XJJ 50J Digital Display Plastic Charpy Impact Testing Machine for Plastic Tester Test Equipment
1. Application:
Charpy Impact Test machine is mainly used for impact toughness test of
plastics, GFPA, FRP, ceramics, cast stone, plastic electrics, electrical insulating material and other non-mental materials. This machine is applicable to the Scientific research colleges and universities authority , Nonmetallic material factory. And other test labs and inspection department for testing.
This machine with wide range of impact energy. Izod and charpy can be in common use. Simple structure, easy operation and high test accuracy.
2. Standard:
1. GB/T 1043-93 Hard plastics charpy imoact testing method
2. GB/T 1843-1996 Plastics izod impact testing method
3. JB/T 8761-1998 Plastics izod impact testing machine
4. JB/T 8762-1998 Plastics charpy impact testing machine
5. ISO 179-1993(E) Plastics-measuring of charpy impact strength
6. ISO 180-1993(E) Plastics--measuring of izod impact strength
7. GB/T 18743-2002 Thermoplastic plastic pipe for fluid delivery charpy impact test method
8. ASTM D256 Plastics anti izod impact testing method
3. Technical parameters:
|
Specimen type |
length |
width |
thickness |
supporting distance |
Jaw model |
|
1 |
80±2 |
10±0.5 |
4±0.2 |
60 |
A |
|
2 |
55(50)±1 |
6±0.2 |
4±0.2 |
40 |
B |
|
3 |
120±2 |
15±0.5 |
10±0.5 |
70 |
C |
|
4 |
125±2 |
13±0.5 |
13±0.5 |
95 |
D |
