HC-C007 Top quality Medical 7 inch CTG Fetal Monitor for sale /Digital fetal heartbeat monitor
Specification:
Fetal Heart Rate:
Transducer: Multi-crystals, pulsed doppler , high sensitive
Strength: <5mW/cm2
Working frequency: 1.0MHz
Signal processing: special DSP system and modern recognization.
Measurement range: 30~210 bpm
Alarm Range:
High limit: 160,170,180,190 bpm
Low limit: 90,100,110,120 bpm
Maximum audio output power : 1.5 Watt
Toco: Measurement range: 0~100 units
Resolution: 1
Pregnant HR Measure: Measure scope: 30bpm~240bpm. Measure accuracy: ±2 bpm
Fetal Movement: Button Hand Count ( Automatic cumulative number of movements
Maternal SpO2 measure: Measure scope : 70%~99%. Measure accuracy: ±3%
NIBP measure:
a) NIBP-SYS (6.7~32.0Kpa) (50~240mmHg)
b) NIBP-DIA (3.4~26.6Kpa) (25~200mmHg)
c) NIBP-MEAN (2.0~24.0ka (15~180mmHg)
NIBP Accuracy: ±1.1kPa (±8mmHg) or ±5% of the results, take the bigger one.
Maximum Mean error: ±5mmHg
Maximum Standard deviation 8mmHg
Measure accuracy: ±2 bpm or ±5% of the results, take the bigger one.
Measure mode: Auto, Manual
Pulse Rate Accuracy: Maximum Mean error: ±2bpm
Power Consumption: < 20W
Dimension: 295W×240D×73H(mm)
Power: a.c.100-240V,50/60Hz or 8.4 Li-LON
Working Environment: Temperature: 5~40°C. Relative humidity: 10~80%
Net weight: 1.75kg
Optionals:
|
Twins monitoring Maternal SpO2, NIBP, PR, ECG, RESP, TEMP |
A: Firstly we confirm product details and then send the Proforma Invoice,
You make payment to us through Trade Assurance or T/T, Western Union or MoneyGram,
after we confirm your payment then ship the product to you once finished production.
2. For HC-C002 Best price multiparameter patient monitor with 8 inch patient monitor / medical 8 inch patient monitor product, What’s the minimum order quantity (MOQ)?
A: For disposable material,We have our own MOQ,For our HC-C002 Best price multiparameter patient monitor with 8 inch patient monitor / medical 8 inch patient monitor, our MOQ:1pc,
3. What is your warranty?
A: For most products the warranty is for 12 months, some products we provide 18 months warranty.
For HC-C002 Best price multiparameter patient monitor with 8 inch patient monitor / medical 8 inch patient monitor, we provide 12 months warranty.
4. What’s your delivery time?
A: Generally it is 5 working days if goods in stock. within 10 working days if the goods need production,
5. How to ship the product?
A: The shipping way normally depand on your quantity,total CBM and weight.
We have our own shipping company to provide best shipping cost and efficient way.
