IS200STCIH2A is a Simplex Contact Input terminal board developed by GE under Mark VI series. The Simplex Contact Input terminal board is a small contact input terminal board designed for DIN-rail or flat mounting. The board accepts 24 contact inputs with nominal 24, 48, and 125 V dc excitation from an external source. The contact inputs have noise suppression to protect against surge and high-frequency noise. The PAIC I/O Pack is compatible with the module. The I/O pack plugs into the D-type connector and communicates with the controller via Ethernet. Only simplex systems are supported.

IS200STCIH2A

The IS200STCIH2A is a Mark VIE terminal board. This board is terminated with external I/O.  This is mostly used with GE Speedtronic Mark VIE series. In addition, the Mark VIE is a flexible platform for multiple applications. It also provides high-speed networked I/O for simplex, dual, and triple-redundant systems.

IS200STCIH2A is a multilayer PCB populated with SMD components and connectors. One part of the termination block is a removable connector. STCI  terminal boards are available in different revisions also.

Reliability

IS200STCIH2A board is very reliable and so less prone to damage. But the improper handling and poor storage can affect the functionality of the card. So that we recommend keeping the cards in static sensitive storage boxes in recommended conditions.

Repair

If you experience any issue with IS200STCIH2A, we can quickly test, diagnose and fix it. Expedite repair option is also available for IS200STCIH2A. The cards are repaired using proper tools and experts in a controlled environment. All the parts needed for repairing IS200STCIH6A are in our stock. We also ensure that the replacement components are industrial grade and meet or exceed OEM standards. FVT tested all repairs and comes with a warranty.

Refurbishing

Proper refurbishing of the IS200STCIH2A circuit board can increase its longevity also.

The refurbishing process includes,

Replacing all aging and commonly failing components.

Applying TIL modification if there is any.

Reflowing solder to eliminate dry solder.

Thorough Industrial standard cleaning of the card.

Applying a protective coating, etc.

Functional Verification Test.

We also carry out the FUNCTIONAL VERIFICATION TEST of IS200STCIH2A in an actual OEM system setup. We will individually verify all inputs and outputs for their functionality. Depending on the board, we do load testing also to ensure the proper stability of the board.

Circuit Board Handling.

IS200STCIH2A is a static-sensitive board. We also recommend minimizing hands-on contact with PCB, especially in the conducting area. If you need to hold them directly, hold them on their edges and wear antistatic gloves. These units needs to handle with proper ESD safety precautions.

RELATEDIS200STCIH6A,

IS200STCIH6A

Buying Options

Brand New

These products are genuine OEM Units.

Sourced from OEM or independent third party channels, and verified by DTC’s Quality Control

Upon customers request we provide a full functional test on these units free of cost

Comes with 2yr DTC warranty.

Certified New

These products are open box genuine OEM items sourced from independent third party.

These units undergo our quality inspection program which involves a full functional verification test and verify the result to match the manufacturer specifications.

Comes with 2yr DTC warranty.

Refurbished

These products are used genuine OEM parts

These units undergo our quality inspection program which involves the complete overhaul and calibration of the unit to match the manufacturer specifications.

Overhauling involves full functional testing, cosmetic repair, components replacement, revision updates, etc and comes with 2yr DTC warranty.

Used

These products are genuine OEM items

Removed from surplus or decommitioned control panels, and verified by DTC’s Quality Control.

These units are Power On tested and comes with 30 day warrenty.

Repair Yours

Our in-House State-of-the art lab is capable of testing and repairing any Industrial Electronic Circuit boards.

DTC Lab is equipped with OEM control panels for full functional test of the subject boards.

We use only OEM recommended or industrial standard parts for replacement.

We not only repair the problem but also replace the aging and commonly failing components even if its functioning at the time of repair which adds the reliability of the circuit board.

Same day turnaround repair service is available upon request

All our repairs are backed by a 2yr warranty.
