Product Details
Brand Name: | Soyo | Place of Origin: | China | Model Number: | S12MV1224-25M |
Product Description
12mm 1.2" 25Megapixel Lenses Manual iris Machine Vision FA 0.39% TV Low Distortion Industrial Recognition 8K Camera Optical Lentz Automatic CCTV Lens C Mount Factory Automation SMT AOI ITS Positioning Measurement Scan
High resolution : 25 megapixel cover all 8K & 4K
Large format : 1.2" size covering 1.1", 3/4, 2/3", 1/1.8", 1/2" camera
Low distortion: 0.39% TV / -0.28% Optical low distortion for machine vision
Application : Automation, machine vision, medical, life science, ITS, SMT, AOI
Model | S12MV1224-25M | |
Resolution | 25 Megapixel | |
Format | 1.2" (2.74μm) | |
Focal Length | 12mm | |
Max image circle | Φ19.3mm | |
Aperture (Close) | F2.4 Manual iris | |
Angle of View (°) | 1.2" | 76.2*62.4*55.33 |
M.O.D | 0.1m | |
Relative Illumination | 81.4% ( WD=300mm F2.8 ) | |
Distortion | 0.39% ( TV ) ; -0.28% (Optical ) | |
B.F.L | 18.5mm , WD=600mm | |
CRA | 6.02° | |
Size | Φ50*66.96mm | |
Projector | Center ≥200lp/mm; Edge Φ16 ≥160lp/mm | |
Mount | C | |
Weight | 300g | |
Marks | AT430~680nm T≥85%; 15G Element |
