Product Description
13mm x 305m fibreglass fish conduit push rod detectable duct rodder
Duct rodder ,also called fiberglass duct rodder,is a powerful auxiliary tool used for rope traction in the pipe. Smooth and flexible surface of the duct rodder can easily make the rope or cable pass through the narrow channel. Glass fiber reinforced plastic wire threading appliance has the advantages of savin time, saving effort and improving efficiency. High temperature strength and bending properties, which make it to go through narrow pipes easily.Outer protect layer are made of ABS, which has good anti-UV capabilityIt is selected as the special tool for pulling cables and optical cables in many fields such as telecommunications, power industry and construction. It also can measure the length of the pipeline, pipe cleaning, acceptance of pipeline.
Specification
 Specification of Fiberglass duct rodder
Size
Rod diameter (mm)
φ4  φ4.5  φ6  φ7  φ8  φ9  φ10  φ11  φ12  φ13  φ14  φ15  φ16  φ18
Rod Length (m)
10-500m
Frame size (cm)
48*44*16; 64*50*17; 98*90*40; 100*111*45; 122*118*45;
Material
Fiberglass rod inner
Extruded by fiber glass and high strength resin at high temperature
Fiber glass rod outer
High Density polyethylene coating
Metal Frame
Steel with high-temperature sprayed plastic or hot dip galvanized






Physical Property
Fiber glass content
75-80%
Density
> 1.9gr/cm3
Working environment
-40° C to +80° C
Minimum Pulling strength
4000N +/-5%
Consistency of rod
137gr/m
Flexural Modulus
> 46.500Mpa
Elongation at break
2.5-3%
Min Bending Radius
388mm
