Aluminium Clad Timber Composite Sliding Patio Door Outdoor Exterior Aluminum Wood Sliding Doors External
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2009
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
America Nfrc Standard Low-e Glass Radiation Protection Made In China Exterior Alu Clad Oak DoorsNegotiableMOQ: 1 -
Exterior External Aluminum Wood Folding Door Wooden Accordion Doors Timber Wood Bifold Door For ResidentialNegotiableMOQ: 1
-
Vinyl Windows Upvc Double Glazed Windows Pvc Sliding Window Plastic Steel WindowsNegotiableMOQ: 1
-
Plastic Windows Vinyl Windows Pvc Upvc Casement Window Windows Doors USANegotiableMOQ: 1
-
Vinyl Windows Upvc Pvc Single Double Hung Window Plastic Steel WindowsNegotiableMOQ: 1
At Puertana, we approach materials differently, holding ourselves to the highest standards for material selection, sourcing, and development. Puertana’s window and door materials—wood, extruded aluminum each offer unique benefits. If you’re not sure what’s best for your project or your climate, a Puertana window and door dealer can help recommend the material with the right attributes.
Product Description
Glass Standard |
Comply with AS2208 / IGCC / CE / ISO |
||||||
Standard/Certificate |
Comply with CE / ISO |
||||||
Thermal Insulation |
U value from 0.8 to 2.0 W/M2k |
||||||
Window Rating |
N6 |
||||||
Sample lead time |
7 days |
||||||
Water penetration |
600 pa |
||||||
Ultimate strength |
4500pa |
||||||
Air infiltration |
75/150 |
||||||
Extrusion alloy |
6063-T5 profile with 2.0-3.0 mm thickness for door |
||||||
Hardware |
China top brand;German brand with 10 year warranty |
||||||
Surface treatment |
Powder coated, Electrophoresis, PVDF, Anodizing, or wood color |
||||||
Packing |
Wooden or Carton Box with Bubble Bag, Clear film,Foam inside. |
||||||
Delivery |
15-35 Days after order confirmed |
||||||
Details Images
There is a safe solution for the simple operation of large and heavy lift-slide systems: The innovative SOFT CLOSE function, which can be invisibly integrated into the sash. This brakes the sash gently just before the end position and then pulls it shut automatically. This minimises any risk of injury in the case of improper operation and precludes any material damage.
Innovative boogie wheels: Putting heavyweights into motion really easily.
Sophisticated product details and the highest quality materials allow sliding doors of all sizes to slide back and forth almost weightlessly. This is achieved by very special bogie wheels which distribute the load of the sash across eight rollers.
Clever convenient solutions: From the enregy store to the positive control.
There is always a magic word for maximum ease of use. When it comes to lift-slide systems, this is "energy storage". A special
spring hidden in the comfort gear uses the weight of the sash to lift it even more easily. The "positive control" is decisive for larger parallel slide & tilt doors: Merely turning the handle moves the sash conveniently into the desired position.
spring hidden in the comfort gear uses the weight of the sash to lift it even more easily. The "positive control" is decisive for larger parallel slide & tilt doors: Merely turning the handle moves the sash conveniently into the desired position.
What does it mean to be an ENERGY STAR-certified window or door?
To obtain ENERGY STAR certification, a window or door must meet a set of requirements that are determined by the U.S. government. Those requirements differ based on geography, meaning a window that’s being installed in Minnesota has different requirements than one in Florida. The certification is meant to indicate that the window is energy-efficient in the region where it will be used, and can help homeowners save on energy costs.
Zone |
Windows |
Doors |
||||
U-Factor |
SHGC |
U-Factor |
SHGC |
|||
Northern |
< 0.27 |
Any |
< 0.30 |
< 0.40 |
||
0.28 |
> 0.32 |
|||||
0.29 |
> 0.37 |
|||||
0.3 |
> 0.42 |
|||||
North Central |
< 0.30 |
< 0.40 |
< 0.30 |
< 0.40 |
||
South Central |
< 0.30 |
< 0.25 |
< 0.30 |
< 0.25 |
||
Southern Zone |
< 0.40 |
< 0.25 |
< 0.30 |
< 0.25 |
||
Wood
Offering a rich, warm look, many customization options, and design versatility, wood is a premium choice. Wood can be used on both the interior and exterior of a window or door. As a lower maintenance option, wood can also be used on only the interior with an extruded aluminum cladding exterior. Puertana offers both options, leading the industry in sourcing, processing, and utilizing high quality wood.
EXTRUDED ALUMINUM
Extruded aluminum is used on window and door exteriors to provide additional protection and minimize maintenance compared to an all-wood window. Aluminum can either be extruded or roll-formed, and the difference in strength can be compared to an industrial chair versus an inexpensive lawn chair. Extruded aluminum is used for cladding because of its strength and weather resistance. It’s important to remember that clad windows and doors are different from products that have all-aluminum frames, which are typically less energy-efficient than the alternatives.
U-FACTOR
Simply put, U-factor measures how well a window keeps heat inside your home. It’s a measure of total heat flow through a window or door from room air to outside air. Lower numbers indicate greater insulating capabilities. It’s a particularly important measure for climates with colder winters.
SOLAR-HEAT GAIN
If U-factor denotes how much heat leaves your home, the Solar Heat Gain Coefficient (SHGC) measures how much radiant heat enters your home. All you really need to remember is: The lower the number, the less heat a window lets in.
VISIBLE TRANSMITTANCE
The amount of visible light transferred through a window. Low E coatings can reject solar heat gain without significant reduction to visible light passing through the glass.
Does my window need to be ENERGY STAR certified in order to be energy efficient?
No. While an ENERGY STAR label can be helpful in identifying energy-efficient windows, every home is unique. ENERGY STAR provides a one-size-fits-all guideline but does not take into consideration, for example, the orientation of the house or the number or size of windows and associated Solar Heat Gain. A window expert like your Puertana dealer can help determine which products will work best for you. ENERGY STAR also recognizes products that meet high energy-efficiency guidelines. Puertana offers the industry’s widest selection of wood and clad wood products that meet these rigorous criteria. Link to Most Efficient product list.
Can you help me to better understand the numbers? What’s a good U-factor number? What’s a good SHGC?
Different homeowners seek out different levels of efficiency, but a “good” U-factor is <.30. A “good” Solar Heat Gain rating, meanwhile, on a scale from 0 to 1, is relative to climates in different regions. Low SHGC numbers are best for southern climates where there’s intense sun exposure, whereas higher SHGC values make the most sense for regions with cold winters.
Can you explain Low E coatings?
The ability of a material to radiate energy (heat) is called its emissivity. Extremely thin coatings of special low emissivity (Low E) metallic material are applied to glass panes used in windows and doors to boost their energy efficiency. Low E coatings, usually applied to the inside layers of insulating glass, manage the amount of light and heat either conducted through a window or reflected away from it.
Are triple pane windows the best? The more panes the better, right?
Not always. Triple-pane windows work best when enhanced energy performance is a key objective. Tripane offers a range of low-E configurations for greater Solar Heat Gain control, including panes filled with argon or krypton-argon gas for added efficiency. But no matter how many panes there are, if the window is poorly constructed, poorly installed or allows air leakage, it will not
be efficient.
be efficient.
INSULATING GLASS (IG)
Two or more glass panes separated by energy efficient inert gas or air to reduce thermal transfer.
LOW E
Low E stands for low emissivity. Microscopically thin, transparent metal or metallic oxide layers deposited on a glass surface suppress radiative heat flow and reflect interior infrared energy (heat) back to the inside, reducing heat loss through the glass. Various Low E coating options can manipulate heat gain to match different climate needs.
GAS FILLS
Argon or krypton mixes slow the movement of warm and cool air in IG airspaces and improve thermal performance.
Company Profile
Founded in 2010,Foshan Puertana building materials Co.,Ltd. is a modernized enterprise that specializes in high-end aluminum alloy doors&windows,solid interior frosted glass doors,sunrooms and shower rooms etc, integrating R&D,manufacturing,sales and service.It covers 30,000 square meters, and has over 500 staffs.
We are One Stop Building Materials Supplier , we mainly working with the Housing Builder, Developer, Contractor and individul houses , most of our customers from North America , Europe , Australia , and our products can meet the local Building Code.
Our Advantages
Certifications
Project Gallery
Product packaging
FAQ
Q: Are you a factory?
A: Yes. We are factory.
Q: What's your payment term?
A: T/T 30% deposit, full balance against delivery
Q: Can you help with delivery?
A: Yes, we can do FOB, CFR, CIF, DDU.
Q: What's your period of production time?
A: Normally it's 25-30 days. It's negotiable.
Q: Will you check the products' quality before delivery?
A: Yes, we have QC department so we can make products 100% good for you.
Q: What color can you do for the products?
A: We have standard colors for every product. But we can customize it for you.
