The highest quality forged brass pulleys
Forged brass sash window pulley
There are relatively few moving parts in a traditional weight and pulley system. Sash have become increasingly heavy with larger glass sizes and double and even triple glazing and the use of very high quality pulleys has become critical. Failure in a pulley (binding, squealing or even a broken axle) results in an improperly operating window. In these cases, repair can be very time consuming and expensive, involving the removal of trim, sash, weather-stripping systems, disassembly of the weight and chain from the sash, installation of a proper high quality sash pulley, reassembly and re-painting. Pulleys are “deeply” built into the construction of and are critical to the smooth operation of a well performing double hung window. It is essential to use the very best.
These sash pulleys are the finest available in appearance, durability, and function. Model PBB 225 pulleys are designed for sash weights up to 1-3/4″ diameter when used in typical 7/8″ thick jambs typical in residential and smaller buildings. Commercial and institutional buildings may require the larger 2-1/2” sash pulley, click here for more information. The pulley is carefully designed with a precisely machined faceplate and the radiused ends allow for rapid, simple and accurate mortising with a standard 1-1/8″ diameter router bit. Housing body = 2-7/8″ X 7/8″ X 1-7/8″ deep.
The solid brass forged and machined housing shields the ball bearing and axle, preventing dirt and grit from affecting performance and assuring many decades of easy operation. The wheel is CNC machined from solid brass stock. The pulley utilizes a chromed steel axle and sealed ball bearing. Available in five finishes: Lacquered Brass, Unlacquered Brass, Oil Rubbed Bronze, Polished Nickel and Satin Nickel.
By using bronze or stainless steel sash chain with these pulleys you virtually eliminate all maintenance to the weight and pulley system.
Dalian ruici industrial co. LTD
Founded in 2005, the company was founded in 1984.Is a specialized in metal products manufacturing enterprises.It mainly produces the OED and ODM products according to customer's requirements.
We mainly engaged in steel, stainless steel, copper, aluminum and zinc alloy products casting, forging, stamping and machining.Application fields include: petrochemical, engineering, Marine industry castings: such as impeller, pump, valve, floor drain, flange;Transmission machinery parts;Kitchen and food industry castings;Auto parts;Agricultural machinery parts, etc.
Our processing equipment includes many common lathe, numerical control, four-axis machining center, milling machine, boring machine, grinding machine, etc.The range of products ranges from 3 grams to 3 tons.Our factory passed the iso9001:2008 quality system certification in 2005, and through BV certification in 2016, the qualified rate of finished products has been controlled above 99%.
Our clients include industry world leaders, medium and multinational companies, providing a full range of production and transportation services for them in the long run.
