Product Overview
YFMB-950 Split semi-automatic Laminating Machine
This machine as a professional equipment used for plastic film laminating on the surface of paper printer matter.
Thermal laminating (Pre-coated /thermal film)
Film: OPP, PET, PVC, METALIC, etc.
FEATURES AT A GLANCE
Widely applicable for laminating in packaging, paper box, books, magazines, calendars, carton, handbags, Gift box, Wine packaging paper improving the printing matter grades, and achieve the purpose of dust-proof, water-proof, oil proof. It’s the best choice for printing and laminating enterprises of all scales.
perforating and cutting knife
automatic overlap
302mm heating system
PRODUCT SPECIFICATIONS
Model |
YFMB-950 |
YFMB-1100B |
Max. paper size(Width) |
920mm |
1040mm |
Paper Thickness |
100-500g/m2
|
100-500g/m2 |
Laminating Speed |
0-30m/min |
0-30m/min |
Power |
15kw |
18kw |
Weight |
1900kg |
2100kg |
Dimension (layout) |
4600*1760*1500mm |
4800*1800*1500mm |
Loading |
By sea |
By sea |
PRODUCT CONFIGURATION
1. SCHNEIDER frequency inverter equipped for infinite speed variation ensures speed adjustment much more convenient and efficient, and makes the machine run stably and quietly.
2.Enlarged size of chromed heating roller is mounted with built in oil heating system which provides balanced laminating temperature and owns excellent temperature persistence.
3.SCHNEIDER PLC system realizes automatic paper separation, breakdown alert for self-protection ctions.
4.Pneumatic film unwinding system positions film.roll more accurately, and makes the loading and unloading of film roll and film unwinding tension much more convenient.
5.Double sets of serrated perforating wheels provide different choices for different specifications of sheets and film.
6.Perfected traction adjusting system makes traction adjustment more convenient and efficient.
7.Corrugating delivery system and vibrating receiving system ensure paper collection more regular and convenient.
8.Omron frequency converter is equipped for infinitely variable speed, and the operator can change the machine's speed easily and guarantee the machine's running stable.
9.Manual paper feeding.
10.Magnetic regulating plate can be adjusted easily to regulate manual paper feeding.
11.High precision of chrome plated heating roller is equipped with built-in oil heating system, which has excellent performance to temperature control. The laminating temperature is adjustable upon applications.
12.Hydraulic pressuring system provides big and steady pressure to guarantee good laminating quality.
13.The combination of air expansion shaft and braking device can adjust film release tension and speed.
14.Film cutter cuts film width to make it meet paper size. The cut film is left on the film release spindle.
15.Film perforating wheel perforates film edge for the automatic cut of laminated paper.
16.Anti-curvature device: when going through anti-curature device, the laminated paper shall be leveled at conce and wont curve again after cut.
17.Pneumatic cutting system
Shipment Packing
FAQ
Q1: What it is advantage of your products?
A1: Easily operation and simply maintenance. Also coat effective in market.
Q2: How long for the guarantee?
A2: 12 month free warranty.
Q3: The engineer is available for overseas services?
A3: Yes, we supply engineer who is good at communication and understand English.
Q4: Why your price is nice than other supplier. (May you was received our machine's quotation but you still can't decided make order now or latter, hope there I not yet miss you.)
A4: We are manufacture and our engineer and worker is local. Furthermore. we are more forcus on developing products not advertisement only.
Q5: What is the brands for the electrical system?
A5: We are using Schneider PLC inverter, Omron and other international brand's parts that ensure the machine could run smoothly.
Q6: Which level of your products in market?
A6: High and mid grade quality with nice price.
Q7: Where are you?
A7: We are located in Machine's city Wenzhou, Zhejiang,China, welcome to visit us while you visit China.
Q8: Will you supply for OEM or ODM orders?
A8: Yes, we are, if you have any advise please let us know that we could make unique machine for you only.
