UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine

UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine photo-1
UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine photo-2
UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine photo-3
UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine photo-4
UGS3004 Automatic Label Roll to Roll Screen Printer Satin Ribbon Reel Silk Screen Printing Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine



Videos

Video demonstration only for reference

Video 01: /watch?v=CZvS2LaQu_Q

Video 02: /watch?v=Eboz9-jmBE8

Video 03: /watch?v=A4jrK3V_7rw

Video 04: /watch?v=o1aToAv8efI

Video 05: /watch?v=nrXqbwCs1ek



Features:

1. The control circuit system is equipped by Japan programmable controller  (PLC)
2. Vacuum suction system on the table, adjustable to the length of printing stroke and position of screen frame

3. Backed up with high precision linear guiding rail, the machine adopts in-service motor and alternate frequency control to reach in reliable and safe operation.
5. The machine has a heavy duty structure and proper layout for convenient operation.



 Parameters:

Model

UGS3002

UGS3003

UGS3004

UGS3005

Printing color

2

3

4

5

Roll Material Width

300mm

300mm

300mm

300mm

Print Area

400*260/mm

400*260/mm

400*260/mm

400*260/mm

Printing speed

300-900pcs/h

300-900pcs/h

300-900pcs/h

300-900pcs/h

Total power

6kw

8kw

10kw

12kw

Dimension

1000*120*130cm

1200*120*130cm

1500*120*130cm

1750*120*130cm



Detailed Images

   UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine

 UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machineUGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machineUGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine

UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine



Our Services

UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine

 Pre-sale Service                                               After-sale Service

A: Inquiry and consulting support                       A: English manuel and video instruction

B: Sample testing support.                                 B: Your technians can get trained in my factory

C: Invoice and Contract confirmation.                C: Engineers available for overseas if necessary



Certifications

UGS3004 Automatic Label Roll to roll Screen Printer satin ribbon reel silk screen printing machine

FAQ

1. What information should i let you know if i want to get a quotation?

A: What is your Max and Min print size in mm?

B: Material thickness and unwinding width

C: Some photos of your finished products

2. Are you a manufacturer

Yes we have been manufacturing such machines over 20 years and also we are a professional exporter.

3. What about the payment term?

Mostly 30%T/T in advanced, 60% when machine is finished after inspection and last 10% against copy of shipping documents.

4. What is the warranty?

Two year warranty after sales (During the warranty period, we respond for free parts dispachment and the buyer is only required to cover the courier express once the machine has any problems. However we do not respond for the consumables and parts broken by mistakingly operation)

5. What is your aftersale service?

Any questions will be responded within 24 hours by email, skype, phone call or whatsapp. In addtion, we have professional engineer available for overseas service.

6. What is the delivery time?

Mostly it takes 10 to 30 workdays after receiving the deposit and confirming the drawing or samples as required.
