Semi Automatic Hologram Plastic PVC ID Card Film Laminating Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1997
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hologram PVC ID Card Heat Lamination Machine for Warranty GuaranteeNegotiableMOQ: 1 -
2020 New Design Eco-friendly Inkless Safety-No VOCs Optical Holographic Packaging Boxes for Wine and CosmeticsNegotiableMOQ: 1
-
10 Mil Teslin 8-up Sheet for PrintingNegotiableMOQ: 1
-
Designated Position Custom Hologram Stamp Label for Decuments ProtectionNegotiableMOQ: 1
-
Hologram Master Shim Supplier With Different Holographic Lens PatternsNegotiableMOQ: 1
Products Description
Product name: Semi Automatic Hologram Plastic PVC ID Card Film Laminating Machine
Card type all PVC, Composite PVC cards
Lamination on regular PVC card, recommended with 0.5 mil overlay
Card thickness from 0.25 mm (10 mil) to 1 mm (40 mil)
High security direct-to-card lamination
Lamination on regular PVC card, recommended with 0.5 mil overlay
Card thickness from 0.25 mm (10 mil) to 1 mm (40 mil)
High security direct-to-card lamination
Product parameter | ||
Item | ID Laminating Machine | |
Speed range | 100~120cards/hr | |
Temperature range | 100° C to 180° C (212° F to 356° F) | |
Weight | 15-18 Kg | |
Power supply | 100-240 V AC, 50-60 Hz, 2 A | |
Environmental Conditions Min/Max operating temperature | 5° / 30° C (59° / 86° F) | |
Humidity | 20% to 65% non-condensing | |
Min/Max storage temperature: | -5° / +70° C (23° / 158° F) | |
Storage humidity | 20% to 70% non-condensing | |
Operating ventilation | free air | |
Warranty | 1 year lamination module, and lamination hot roller) | |
Working Process
High-end laminator designed as a modular system. Different modules can be combined, enabling a multitude of functions and processes. For example, both-sided lamination can be done in one or two separate modules depending on the desired per hour capacity. Also, the cards can be fed to the laminator in landscape or portrait formats, allowing for various printer connections.
Laminates hologram ribbon with all kinds of cards, including optical variable images. Using a temperature-controlled heating roller, an extremely thin hologram foil is applied onto the id card surface. The laminator can be integrated into an automated personalization system or used as a stand-alone system.
Laminates hologram ribbon with all kinds of cards, including optical variable images. Using a temperature-controlled heating roller, an extremely thin hologram foil is applied onto the id card surface. The laminator can be integrated into an automated personalization system or used as a stand-alone system.
Company Profile
FAQ
1. Are you a manufacturer factory or trading company?
We are one of the leading manufacturers of hologram overlay and card overlay laminator in Suzhou city, Jiangsu province, china. Mainly produce security hologram products.
2. What's the handle temperature of the card laminator?
ENVIRONMENTAL CONDITIONS Min/Max operating temperature: 15° / 30° C (59° / 86° F)
We are one of the leading manufacturers of hologram overlay and card overlay laminator in Suzhou city, Jiangsu province, china. Mainly produce security hologram products.
2. What's the handle temperature of the card laminator?
ENVIRONMENTAL CONDITIONS Min/Max operating temperature: 15° / 30° C (59° / 86° F)
3. If laminate with PVC card, any special in thickness?
Lamination on regular PVC card recommended with 0.5 mil overlay.
4. What kind of extra service you can provide?
Our card overlay laminator can be rented for use, and warranty for one year.
Lamination on regular PVC card recommended with 0.5 mil overlay.
4. What kind of extra service you can provide?
Our card overlay laminator can be rented for use, and warranty for one year.
