Module spare parts PR6423002-001-CN

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Outdoor Use In common with all polyester based films, Autotex F157/F207F250 is not suitable for use in conditions of long term exposure to direct sunlight. Touch Screen Surface The touch screen surface on the panel withstands exposure to the following solvents without visible change: Autoflex EB It is recommended to use the Autoflex EB touch display protection film, that can be ordered from the supplier. Cutting oil Paraffin oil Windex1 Cyclohexanol Persil powder in solution1 Wisk Diacetone alcohol Petroleum spirit1 - 1 Extremely faint glossing of the texture was noted. Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Solvents Time Acetone 10 minutes Isopropanol 10 minutes Toluene 5 hours Autoflex EB Section 5 Chemical Resistance 34 3BSE043446R501 Solvent Resistance Autoflex EB withstands exposure to the same chemicals as Autotex F157 or F207 according to section Autotex F157/F207. Outdoor Use In common with all polyester based films Autoflex EB is not suitable for use in conditions of long term exposure to direct sunlight. 3BSE043446R501 35 Section 6 Operator Panel Drawings Communication Ports Figure 1. Part 1 of Drawing No. S-05005, Date 2004-10-27 Ethernet USB Communication Ports Section 6 Operator Panel Drawings 36 3BSE043446R501 Figure 2. Part 2 of Drawing No. S-05005, Date 2004-10-27 RS-232 RS-422 RS-422/485 RS-485 Section 6 Operator Panel Drawings TK212A, Panel 800 - AC 800M 3BSE043446R501 37 TK212A, Panel 800 - AC 800M Figure 3. Drawing 3BSC630197 Rev. A (2004-09-28) TK854V030, Panel 800 Programming Cable RS232 Section 6 Operator Panel Drawings 38 3BSE043446R501 TK854V030, Panel 800 Programming Cable RS232 Section 6 Operator Panel Drawings PP835 Outline 3BSE043446R501 39 PP835 Outline Figure 4. Part 1 of Drawing No. S-05055, Date 2004-10-26 PP835 Outline Section 6 Operator Panel Drawings 40 3BSE043446R501 Figure 5. Part2 of Drawing No. S-05055, Date 2004-10-26 3BSE043446R501 41 Section 7 Additional Installation Tips When experiencing communication problems in for example noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. Grounding the Operator Panel Section 7 Additional Installation Tips 42 3BSE043446R501 Grounding the Operator Panel 1. The operator panel’s mounting clamps do not provide a secure grounding connection between the panel and the device cabinet. 2. Connect a 2.5 mm2 wire between the operator panel’s quick-connect plinth and the panel chassis. 3. Connect a 6 or 4 mm2 wire or grounding braid between the panel’s chassis and the closest grounding point on the door. 4. Connect a strong but short grounding braid between the door and the device cabinet. 5. Twist the cables onto the 24 V DC feed. 1 2 3 4 5 6 Door Operator panel Ferrite core Mounting plate in the cabinet Power supply 24 V DC Section 7 Additional Installation Tips Ethernet Connection in the Panel 3BSE043446R501 43 6. A ferrite core suppresses disturbances to the 24 V feed. 2 turns around the ferrite core provide 4 times the suppression of 1 turn. 3 turns around the ferrite core provide 9 times the suppression of 1 turn. Ethernet Connection in the Panel 1. In some industrial units for Ethernet, the RJ45 contact’s shield is connected to the chassis via a capacitor. The grounding wires should be short and the conductor should have a large area. A long, thin grounding wire has a very high impedance (resistance) at high frequencies and will not guide disturbances to the ground. Multi-wire conductors are better than single wire conductors with the same area. A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. 1 2 3 4 5 5351 1-1 2-2 3-3 8-8 Industrial Ethernet RJ45 RJ45 RJ45 RJ45 RJ45 RJ45 RJ45 RJ45 Operator panel Operator panel Operator panel Operator panel Shielded Short and unshielded 0.1 uF 250 V To Achieve Better EMC Protection Section 7 Additional Installation Tips 44 3BSE043446R501 2. The operator panel’s Ethernet shield is directly connected to the chassis. Check whether the other Ethernet unit has its shield directly grounded or grounded via a capacitor. In many cases, connecting the shielded Ethernet cabling to the chassis at both ends is inappropriate. Hum or grounding loops can occur. Unshielded cabling may even result in fewer communication errors. A good solution may be to use a shielded Ethernet cable, but to connect the shield at one end only. 3. One option is to break the shield. 4. A more elegant method is to expand the shielded Ethernet cabling with a piece of unshielded Ethernet cable. 5. You can ground the shield via an external 0.1 uF/250 V plastic capacitor. This will connect the HF transients to the ground.
