Taijia LWGY Natural Gas Output 4-20mA RS485 Digital Air Turbine Flow Meter 3 Inch Flowmeter Flow Meter
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Taijia LWGY 4-20mA Digital LCD DN50mm Oil Turbine Water Flow Meter Gas Turbine Flow Meter
-
Taijia LWGY Wide Measure Range Dn150 Water Flowmeter 4-20Ma Liquid Turbine Flow Meter
-
Taijia LWGY Natural Gas Turbine Flow Meter Digital Flow Meter Water Turbine Water Flow Meter
-
Taijia LWGY 4-20mA DN50 Turbine Flow Meter for Liquid Fuel Gas Turbine Flow Meter
-
Taijia LWGY Turbine Hydraulic Oil Flow Transmitter Clean Liquid Turbine Flow Meter Turbine Flow Sensor
-
Taijia LWGY Natural Gas 4-20mA LCD Liquid Flow Meter Turbine Flow Meter Diesel Flow Meter
Product Description
Product Description
Specification
Place of Origin | China |
Brand Name | Tmeasurement |
Model Number | TEMGB |
Type | Turbine Flowmeter |
Output | 4-20mA |
Accuracy | ±1.0%/1.5% of Rate |
Operating Temperature | -20...+60℃ |
Body Material: | SS304;SS316 |
Fluid Temp (liquid) | -20...+150℃ |
Rotor Material (liquid) | 2Cr13; CD4MCu |
Bearing Material (liquid) | Tungsten Carbide |
Rotor Material (gas) | Aluminum alloy, Plastic ABS |
Item | TEMGB Turbine Flowmeter |
Type | Turbine Flowmeter |
Fluid entering the meter first passes through an inlet flow straightened that reduces its turbulent flow pattern. Fluid then passes through the turbine, causing the turbine to rotate at a speed proportional to fluid velocity. As each turbine blade passesthrough the magnetic field generated by the meter's magnetic pickup, an AC voltage pulse is generated. These pulses provided an output frequency that is proportional to volumetric flow.
The turbine wheel is mounted on the main shaft, with special high precision, low friction ball bearings. The turbine wheel has helical blades that have know angle relative to the gas flow. The conditioned and accelerated gas drivers the turbine wheel with an annular velocity that is proportional with the gas velocity.
