Taijia 2021 New Generation Open channel ultrasonic flow meter river water flow measuring Open channel ultrasonic flowmeters

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

UTG21-DR Open Channel Flow Meter.

UTG21-DR Open channel flow meter used to the measurement of flow within open, partially-filled and free flow channels and the open channel flow meter must be used with the measuring weirs and is mainly used to measure sewage flow within the channel under an open, partially filled and free flow conditions.

Specification

Items			Integral	Remote
Measuring range	Instantflow	0.1L/s~120000 m3/s
		Level	0.35m~3.000m
Measuring accuracy	Flow	Triangular weir 1 ~ 5%/rectangular weir 3 ~ 5% / Parshall flume 2 ~ 3%
		Level	±0.3% FS (standard condition )
Cumulative flow			4000000000m3
Dead band			0.35m
Pressure			Below 3 barometric pressure / 2000m below sea level
Meter display			Displays instantaneous flow and cumulative flow, liquid level, echo waveforms and historical curves
Power supply			DC18~36V / 100mA or AC85~265V / 3W
Flow recorder			Can query the cumulative flow of any time during the last 8 years
Output	Analog current	12bit, with load of less than 500 Ohm
		Digital signal	RS485/ModBus agreement
		Switching value	Switching values of 2~4 circuits
Temperature	Environment	-20℃ ~ +60℃
		Process	-20℃ ~+90℃ (specify in order where a temperature of over +60℃ is a necessity)
Interface	Electric	M20×1.5mm	PG11 waterproof connector
		Process	G2”
Materials	Transmitter	Aluminum alloy	ABS
		Probe	ABS / ETFE / PTFE
Waterproof Level			IP67	IP65
Explosion protection class			EX d[ia]iaⅡBT4*	N/A
