300kn 10kn Digital Cement Compression Machine for compressive strength and flexural strength
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- Digital display hydraulic testing machine 3000kn compression testing
- 2000kn compression testing concrete cube test machine
- triaxial compression test machine/pressure testing machine
- Digital Type Concrete Compression Testing Machines
- Digital Display Hydraulic Testing Machine with best price
- 2000kN hand operated compression testing machine
Product Description
Product Usage and Features
HYE-300D Concrete Anti folding and Anti compression Machine
EQUIPMENT INTRODUCTION:
The series of testing machines are powered by hydraulic pressure. Electro-hydraulic servo control technology is used to test the mechanical properties of cement, mortar, brick, concrete and other building materials. It shows the loading force value, loading speed and loading curve. The test data is automatically processed, stored, and printed. PRODUCT FEATURES:
1.Using 300KN and 10KN high precision load cells;
2.Use special clamp of anti-pressure and anti-folding fixtures;
3.Adopt a perspex glass protective cover;
4.Servo motor plus ball screw, no noise, high con1 precision;
5.220V power supply energy saving and environment protection.
5.220V power supply energy saving and environment protection.
APPLICATION STANDARD:
GBT、ISO、ASTM、DIN、JIS etc.
Parameters
Model | HYE-300D | HYE-300B |
Compressiveflexural maximum test force(KN) | 300/10 | 300/10 |
Test accuracy | Level 0.5/1 | Level 0.5/1 |
Compressive piston stroke | 80mm | 80mm |
Anti-floding piston stroke | 60mm | 60mm |
Compressive compression space | 180mm | 180mm |
Flexural compression space | 180mm | 180mm |
Fied upper platen size | Φ108/Φ60mm | Φ108/Φ60mm |
Ball-type upper platen size | Φ168mm | Φ168mm |
Lower platen size | Φ207mm | Φ207mm |
Motor power | 1.5KW | 0.75KW |
Mainframe dimensions | 560*400*1340mm | 560*400*1340mm |
Machine weight | 520kg | 520kg |
Control cabinet dimensions | 540*500*820mm | 540*500*820mm |
