2000KN Concrete Pressure Testing Machine Digital Display Concrete Compression Testing Machine CTM
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electric Digital Display Compression Testing Machine 3000KN Manufacturer PriceNegotiableMOQ: 1 -
AUTOMATIC Compression Testing Machine Digital Compression Testing Machine 3000KnNegotiableMOQ: 1
-
300t Computer Control Compression Testing Machine for Concrete CubeNegotiableMOQ: 1
-
Concrete Compressive Strength Testing Machine PriceNegotiableMOQ: 1
-
Digital Automatic Concrete Compression Strength Testing Machine Factory PriceNegotiableMOQ: 1
2000KN concrete pressure testing machine Digital Display Concrete Compression Testing Machine CTM
Usage Overview
The series of testing machines are powdered by hydraulic pressure. Manual control technology is used to test the mechanical
properties of rock, mortar, brick, concrete and other building materials. It shows the loading force, loading speed etc. Test data
are automatically processed, stored and printed. This series of testing machine takes hydraulic pressure as power and manual
loading to test the compressive mechanical properties of concrete, brick, stone and other building materials. It can display
loading force value and loading speed value digitally. It can be configured with computer to display loading curve and carry out
data collection and processing.
properties of rock, mortar, brick, concrete and other building materials. It shows the loading force, loading speed etc. Test data
are automatically processed, stored and printed. This series of testing machine takes hydraulic pressure as power and manual
loading to test the compressive mechanical properties of concrete, brick, stone and other building materials. It can display
loading force value and loading speed value digitally. It can be configured with computer to display loading curve and carry out
data collection and processing.
Product Description
Specification
Mode No |
DYE-2000 |
DYE-2000A |
Product name |
Pad type digital compression testing machine |
Manual screw digital compression testing machine |
Maximum test force |
2000KN |
2000KN |
Test accuracy |
Level 1 |
Level 1 |
Space adjustment method |
Pad adjustment |
Manual screw adjustment |
Piston stroke |
80mm |
80mm |
Sensor type |
Oil pressure |
Oil pressure |
Maximum spacing between two pressure plates |
350mm |
350mm |
Upper platen size |
225 |
240*240 |
Lower platen size |
295 |
350*260 |
Motor power |
0.75 |
0.75 |
Mainframe dimensions |
900*400*1250 |
985*600*800 |
Mavhine weight |
920 |
900 |
Unpacking display
Our Advantages
Installation and training
· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
· Without visiting, we will send you user manual and video to teach you to install and operate.
After Service
· One year guarantee for whole machine.
· 24 hours technical support by email or calling
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
