HYE-2000T Electro-hydraulic Servo Compression Testing Machine

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

HYE-2000T Electro-hydraulic Servo Compression Testing Machine

Usage Overview

This series of testing machines are suitable for concrete and rock compressive strength tests, equipped with appropriate fixtures and measuring devices to meet the concrete split tensile test, flexural test, and static elastic modulus test.

1. This machine is specially designed for concrete elastic modulus test. It is equipped with professional elastic modulus analysis software and automatic data collection kit. The test process is simple and efficient;

2. This machine adopts a large oil cylinder wide body design, which has a large test space, while reducing the internal pressure of the hydraulic system, making the test process safer and more reliable;

3. This machine uses a combination of servo motor and Mazu gear pump to load, the test process is quiet, and the test data is accurate;

4. This machine adopts a servo control system, which can realize constant rate control, load holding control, low cycle control, stepless speed regulation, and online adjustment of PID parameters;

5. This machine can be used for compressive tests of concrete test blocks, refractory bricks and other blocks, realizing one machine for multiple purposes;

6. Adopting block slide rail structure design, free switching between concrete compression test and elastic modulus
test;

7.The Chinese and English interface can be switched freely, making it more convenient and faster for foreign customers to
use.

Name	compression testing machine
Model	HYE-2000T
Max. Test Force (KN)	2000 KN
Test accuracy	Level 1/0.5
Force Value Display Range	1%-100%FS
Force Value Display Error	within ±1%
Framework Type	4 columns
Compressed space	320 mm
Piston Stroke	80 mm
Piston Displacement Velocity	0-60 mm/min
Upper Pressure plate size	φ300mm
Lower Pressure plate size	300*300mm
Effective Distance Between Columns	350 mm
Host Size	5459001260 mm
Control Cabinet Size	6544501300 mm
Total Weight	1300kg

Our Advantages

Installation and training

· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.

· Without visiting, we will send you user manual and video to teach you to install and operate.

After Service

· One year guarantee for whole machine.

· 24 hours technical support by email or calling

Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated

our customer

Company Profile

` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.

· All our products are made in China .Excellent quality with competitive price

Packing & Delivery

· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company

FAQ

Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.

Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.

Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.

Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.

Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.

Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
