Microcomputer Electronic Steel Strand Tensile Stress
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CBR Test Equipment CBR Kits /AccessoriesNegotiableMOQ: 1 -
Calibration Compression Force Transfer Apparatus and Load Cell 2000knNegotiableMOQ: 1
-
High Accuracy 200 Ton Compression Load CellNegotiableMOQ: 1
-
Concrete Cube Compression Testing Machine Compression Force Test MachineNegotiableMOQ: 1
-
Compaction & CBR Test Equipment CBR Kits /AccessoriesNegotiableMOQ: 1
WSC Steel Strand Stress Relaxation Universal Tensile Testing Machine
Microcomputer Controlled Steel Strand Stress Relaxation Tester is used for tensile stress relaxation test of prestressed steel wire, steel strand, PC steel bar and metal material; isothermal stress relaxation test; stress relaxation test period ≥1000h. The isothermal stress relaxation test is to maintain the sample from the initial force F0, determine the change in force on the sample; stress relaxation test period 100h ~ 1000h can be set. Relaxation rate, dedicated stress relaxation tester software, which can perform functions such as uniform rate loading, force retention, and strain retention.
Product Description
Specification
Product name | WSC-300 Microcomputer Controlled Steel Strand Stress Relaxation Tester |
Maximum relaxation test force | 300KN |
Relative error of indication | ≤±1% |
Effective measurement range | 0.4%-100%(Full range without binning) |
Relative error of test force indication | ≤±0.5% |
Slack load loading rate | 0.1~10kN/S |
Screw movement adjustment rate | 0.01-150mm/min |
Steel strand loose deformation gauge distance | 200mm |
Effective measurement space | 1300mm |
Effective gauge length | ≤1200mm(Φ60) |
Deformation measurement resolution | 0.01mm |
Steel strand nominal diameter（mm） | ≤15.24 |
Stress relaxation test procedure | Force closed loop,deformation closed loop control |
Mainframe dimensions | 2590*700*1150mm |
Power | 220V、50Hz、3kW |
Weight | 1500kg |
Our Advantages
Installation and training
· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
· Without visiting, we will send you user manual and video to teach you to install and operate.
After Service
· One year guarantee for whole machine.
· 24 hours technical support by email or calling
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
