Concrete Coating Thickness Gauge With Best Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Concrete Floor Slab Thickness Gauge/Construction & Engineering TestNegotiableMOQ: 1 -
Ultrasonic Concrete Crack Depth Meter PriceNegotiableMOQ: 1
-
Ultrasonic Concrete Crack Detector Crack Depth Meter Factory PriceNegotiableMOQ: 1
-
Road Marking Testing Reflectance and Coefficient Measuring InstrumentNegotiableMOQ: 1
-
Handhold Professional Retroreflectometer Road Marking TestingNegotiableMOQ: 1
LBY Concrete Thickness Detector
Product Description
LBY Concrete Thickness Detector is a portable non-destructive testing instrument for measuring the thickness of concrete or other non-ferromagnetic media. When used, the transmitter and receiver probes are placed on the two relative test surfaces of the Concrete, respectively, transmitting and receiving electromagnetic fields. The instrument transmits and receives electromagnetic fields according to the received signals. Strength, test Concrete thickness.
Product Details
Product mode | LBY |
Host parameters | Screen size: 5 inch LCD resolution:160x128 Volume: 195x140x45mm weight |
Host housing | Waterproof, dustproof, shockproof |
Thickness test range | 40~820mm |
Test Accuracy | 40~500mm: ±1mm, 501~600mm: ±2mm, 601~700mm: ±4mm; 701~800: ±8mm |
200Data storge capacity | 200 Components or 30,000 Measuring Points |
Data transmission mode | Wireless Cloud Transport (Options) |
Powder supply | Both host and transmitter probes are built-in lithium batteries |
Working environment | Temperature:-10~40℃ Humidity: ＜90%RH |
Non-strong alternating electromagnetic field | |
It shall not to be exposed to direct sunshine for a long time | |
Packing specification | Material: engineering plasic volume: 420x140x335mm weight: 6.5kg |
Detailed Images
1.Upgraded wireless cloud transmission function;
2.Adopt three anti-shell design, waterproof, dust-proof and shock-proof;
3.Separate design of probe and main engine facilitates on-site measurement and use by operators.
4.Store the measurement results of floor thickness according to components.
5.Simple and easy to use, with perfect measurement, storage and analysis functions;
6.Stored data is transmitted to computer through USB interface.
7.Use Windows software to analyze data and generate test reports.
2.Adopt three anti-shell design, waterproof, dust-proof and shock-proof;
3.Separate design of probe and main engine facilitates on-site measurement and use by operators.
4.Store the measurement results of floor thickness according to components.
5.Simple and easy to use, with perfect measurement, storage and analysis functions;
6.Stored data is transmitted to computer through USB interface.
7.Use Windows software to analyze data and generate test reports.
Company information
Cangzhou Lovely Technology Co., Ltd is specialized in Nondestructive Test Instrument and Material testing machine over 10 years,Without advanced technologies and best customer service, Our product has exported to more than 100 countries and regions,which win favorable comments from customers worldwide.
Cangzhou Lovely Technology Co.,Ltd. insisted on "Integrity-based, guests supremacy". Welcome customers from all over the world to visit us for business negotiation!
The Foreign Trade Department of Cangzhou Lovely Group Co.,Ltd. was established.
According to customers' requirements, there has the machine---CZY5 Rebar Weighing and Length Measuring Instrument
Independent research and development and production of GW50 Automatic Rebar Bending Testing Machine.
L800 Integrated Floor Thickness Gauge RBL+ Rebar Detector goes public.
New product-- U900 Series Non-Metallic Ultrasonic Detector.
HYE-2000 Series Microcomputer Servo Compression Testing Machine: Pad adjustment, Manual screw adjustment, Electric screw adjustment.
WAW-B Micro Electromechanical Liquid Servo Universal Testing Machine.
EV2 Static Deformation ModulusTester; EVD Dynamic Deformation Modulus Tester. ---Patented Product
The factory was established, begin to produce more than 20 types instrument.
Our Services
Pre-sale service
* OEM customized service
* Equipment installation and calibration
* Equipment installation and calibration
* Free technical training for visiting factories
After-sales service
* 24-hour Online consulting support.
* Training how to instal use the machine.
* the professional after-sale service team will provide perfect technical support
Packing & Delivery
We promise the delivey in time. And we support customize products for customers. Such as the voltage and package etc. All wooden box are suitable for exporting.
FAQ
Q1:Are you a factory or trading company?
A:We are a factory specializing in manufacturinf all kinds of tester.
Q2:Where is the loading port?
Q2:Where is the loading port?
A:Qingdao port or tianjin port.
Q3:What’s the MOQ of the product?
A:Different item has different MOQ.normally one stand is preferred.
A:Different item has different MOQ.normally one stand is preferred.
Q4:What certificates do you have? A:We have ISO 9001.
Q5:Do you have an OEM service?
A:Yes.We can provide OEM and ODM services as your requirements.
Q6:How long is the production cycle after ordering?
A:General it is about 7-20 days.
Q7:What is the payment method?
A:T/T payment is preferred and other payment terms is accepted.
Q8: Could you support to customize?
A: Yes, we could customize the package and Voltage as request.
A:T/T payment is preferred and other payment terms is accepted.
Q8: Could you support to customize?
A: Yes, we could customize the package and Voltage as request.
