Cheap Portable Rebar Detector Rebar Scanner for Sale
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Wholesale Portable Cover Meter Concrete Rebar Locator Scanner Detector Cheap Price
-
Crack Depth Measurement in Concrete
-
Crack Depth Meter NDT Instruments
-
Anvil Test Steel Anvil For Concrete Test Hammer Calibration Anvil for Sale
-
Standard Calibration Steel Anvil For Portable Concrete Test Hammer Calibration Anvil Price
-
Latest Standard Test Anvil for Test Hammers/ Anvil Rebound Test Factory Price
Product Description
Cheap portable rebar detector rebar scanner for sale
Usage Overview
The first generation portable rebar integrated detector uses an electromagnetic induction method, which can detect the rebar location and cover thickness & diameter accurately, store, transfer and analyze the real time test data. The model is the pinnacle of work with the modern simple design, incorporating the handy & durable features and sophisticated electronic technology. series rebar detector is mainly used to test the location, distribution, direction, the thickness of rebar and the diameter of cover in concrete structure such as walls, columns, beam-slabs etc. It can also detect the location of pipelines and metal embedded parts. The multiple coil structure design make it more accurate＆responsive and higher resolution.
Product Description
Specification
Items | Technical Spec. | ||
Diameter Measuring Range（mm） | Ф6～Ф50 | ||
Measuring Range（mm） | Location Range: 1～120 First Range: 1～60 Second Range: 30～120 | ||
Thickness Measuring Accuracy（mm） | 1～40 | ±1 | |
41～60 | ±2 | ||
61～80 | ±3 | ||
81～100 | ±5 | ||
101～120 | ±8 | ||
Rebar Location Accuracy | 1～60 | ±3 | |
61-120 | ±6 | ||
Diameter Measuring Modes | Optional | ||
JGJ Measurement | Optional | ||
Data Storage | Optional | ||
Off Time | Automatic | ||
Power Supply | Rechargeable Lithium Battery | ||
Working Temperature | -10℃～+42℃ | ||
Size（mm） | 188×145×140 | ||
Weight（kg） | 0.745 | ||
Unpacking display
Our Advantages
Installation and training
· If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
· Without visiting, we will send you user manual and video to teach you to install and operate.
After Service
· One year guarantee for whole machine.
· 24 hours technical support by email or calling
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
our customer
Company Profile
` Cangzhou Lovely Group Co.,Ltd. is a professional manufacturer specializing in Testing Equipment,Universal Testing Machine ,Asphalt Tester,Test Moldsand Soil Road Lab Tester,supply verious type of products ..... We assure high quality to you.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
FAQ
Q1: Are you a factory or trading company? A: We are a factory specializing in manufacturing all kinds of scaffolding material.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
Besides, we could also purchase products as request.
Q2: Where is the loading port?
A: Tianjin port or Qingdao Port.
Q3:How to choose the Transportation Term? A:Usually,we may according to your needs,we may choose the most rasonable freight,then
to select for you.
Q4: What certificates do you have?
A: We have ISO 9001, CE, SGS.
Q5: Do you have an OEM service?
A: Yes. We can provide OEM services according to your requirements.
Q6: What are the payment terms?
A: T/T payment is preferred and other could be accepted, such as L/C, D/P, Western Union, PayPal etc. It is negotiable.
