XSY Steel Bar Rebar Corrosion Detector
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
Product Description
Product Usage and Features
XSY Rebar Corrosion Detector
USAGE OVERVIEW:
Corrosion of steel bars in structural concrete reduces the effective section area and enlarges the volume of steel bars, which leads to expansion, spalling of concrete, reduction of bonding force and bearing capacity between steel bars and concrete, and directly affects the safety and durability of concrete structures. Therefore, the detection of steel corrosion in concrete structures is an important part of the safety assessment and appraisal of existing buildings.
PRODUCT FEATURES:
1.New upgrade, three - proof shell design, waterproof, dustproof, shockproof;
2.XSY debar corrosion detector adopts the polarization electrode principle and measures the surface potential of concrete through the copper/copper sulfate reference electrode. It judges whether the steel is corroded and the degree of corrosion according to the potential size generated by the steel corrosion or the potential gradient formed.
3.Measure the surface potential of concrete so as to achieve the non-destructive testing of corrosion degree of steel reinforcement in concrete;
4.Store the potential value at the corresponding position of each measurement area and display it graphically, and transfer the data to the upper computer software, and operate on it.
Parameters
![](http://timg.china.cn/0/1_126_112388_750_177.jpg)
Potential electrode | Size: Ф30mmx120mm Weight: 100g |
Host parameter | Waterproof level: IP65 Screen size: 5 inches Volume: 195x140x45mm Weight: 0.8kg |
Power supply | Built-in lithium battery |
Potential measurement range | ±1000mV |
Test accuracy | 1mV |
Measuring point spacing | 1 to 100cm |
Data storge capacity | 5400 survey areas/ 228, 000 points data |
Working temperature | -10~40℃ |
Packing specification | Material: engineering plasic Volume: 420x140x335mm Weight: 5.5kg |
Detailed Images
![](http://timg.china.cn/0/1_802_112030_750_698.jpg)
![](http://timg.china.cn/0/1_720_111862_750_489.jpg)
![](http://timg.china.cn/0/1_261_111596_750_750.jpg)
![](http://timg.china.cn/0/1_425_111756_750_750.jpg)
Application
![](http://timg.china.cn/0/1_156_112438_750_250.jpg)
![](http://timg.china.cn/0/1_252_112478_750_50.jpg)
Contact US
![](http://timg.china.cn/0/1_343_112142_750_400.jpg)
Cangzhou Lovely Group Co., Ltd. is specialize in Nondestructive Test Instrument and Material Test Machine over 10 years, Without advanced technologies and best customer service, Our product has exported to more than 100 countries and regions, which win favorable comments from customers worldwide.
![](http://timg.china.cn/0/1_362_111982_750_750.jpg)
We adhere to the high standards of product quality, strict requirements, adopting the world-class production equipments, advanced management and production experience, developing the high-quality testing instruments.
![](http://timg.china.cn/0/1_717_112540_750_400.jpg)
We have has strong sales team and a comprehensive service process to serve end customers around the world.If you have any inquiry or concern,Sales and after service department will reply you within 24 hours.
Our Customers and patent certificate
![](http://timg.china.cn/0/1_152_112536_750_428.jpg)
![](http://timg.china.cn/0/1_904_112942_750_50.jpg)
![](http://timg.china.cn/0/1_451_112518_750_300.jpg)
Packing & Delivery
![](http://timg.china.cn/0/1_46_111744_750_400.jpg)
![](http://timg.china.cn/0/1_235_112656_750_400.jpg)
Why Choose us ?
Get our in-time reply via email or telephone or instant messenger;
Get best product with excellent quality and competitive price;
One year guarantee for whole machine 24 hours technical support by email or calling teach you to install and operate,always enjoy our considerable & full-side after-sales service;
Feel very convenient since we can help you sourcing and ship products from different factories via one shipment, which to a large extent save your time and cost;
Easily make the payment via West Union, Paypal, T/T for small value order;
