Factory High Quality Ultrasonic Tester Concrete Ultrasonic Pulse Velocity Tester

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Factory high quality ultrasonic tester concrete ultrasonic pulse velocity tester

Usage Overview

Product Description

Specification

Product Model	U910	U920	U930
Master control unit	Buit-in A8 industrial control motherboard	Buit-in A8 industrial control motherboard	Buit-in A8 industrial control motherboard
Display	10.1 inch, high brightness, TFT color LCD capacitive screen	10.1 inch, high brightness, TFT color LCD capacitive screen	10.1 inch, high brightness, TFT color LCD capacitive screen
Operational mode	Touch screen	Touch screen	Touch screen
Storage mode	Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk	Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk	Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk
Data transmission mode	Wireless Cloud Transport(Options)	Wireless Cloud Transport(Options)	Wireless Cloud Transport(Options)
Acquisition mode	Single-channel manual point-by-point acquisition	Manual point-by point collection of single and double channels	Single and double channel automatic continuous and acquisition
Number of dispossable profiles	-		Tow
Channel number	1 transmit+1 receive	1 emission+2 reception	1 emission+2 reception
Trigger mode	Signal triggering	Signal triggering	Signal triggering
Sampling period(mus)	0.05~409.6 Multistage Options	0.05~409.6 Multistage Options	0.05~409.6 Multistage Options
Acoustic time accuracy(us)	0.05	0.05	0.05
Acoustic time range(mus)	+1677700	+1677700	+1677700
Width measurement function	Measuring range: 0~10mmMeasurement accuracy: 0.01mm	Measuring range: 0~10mmMeasurement accuracy: 0.01mm	Measuring range: 0~10mmMeasurement accuracy: 0.01mm
Dynamic range(dB)	0.5	0.5	0.5
Emission voltage(V)	Sixty-five, 250, 500 and 1000 gears adjustable	Sixty-five, 250, 500 and 1000 gears adjustable	Sixty-five, 250, 500 and 1000 gears adjustable
Communication interface	UBS, Bluetooth, Wifi	UBS, Bluetooth, Wifi	UBS, Bluetooth, Wifi
Working hours(h)	More than 8	More than 8	More than 8
Power supply mode	Built-in lithium batteryExternal 220V~ 16V AC/CD	Built-in lithium batteryExternal 220V~ 16V AC/CD	Built-in lithium batteryExternal 220V~ 16V AC/CD
Working environment	Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%	Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%	Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%
Host size(mm)	30020055	30020055	30020055

Unpacking display

Our Advantages

1.New upgraded wireless cloud transmission function; 2.Five functions of measuring pile, measuring strength, measuring defect,
sounding depth and width measuring; 3.Stable performance and powerful function, it is the best choice for users with diverse needs
such as engineering inspection, teaching and scientific research; 4.Semi-transparent, high-brightness, TFT color LCD screen;
5.Full touch screen operation, simple and convenient, stable and reliable; 6.Large memory capacity and working time of more than
10 hours; 7.It can be connected with the probe of digital display rebound instrument to measure the strength of ultrasonic
rebound; 8.U-disk transfers data and supports software upgrading through U-disk; 9.Special analysis software is powerful, data
analysis and processing, report generation, and report printing can be completed easily .
