AT610 Hinge Comprehensive Testing Machine is used for physical and mechanical properties test of door & window hinge. It is suitable for turning force test, positioning function test, self-return test, repeated opening & closing test, ultimate bearing capacity, etc.
|
JG/T 125 |
|
|
Note: this Hinge Comprehensive Testing Machine can conform to but not limit to all the standards above, for more standards conformance, please contact us.
1. Our Hinge Comprehensive Testing Machine consists of main machine, steel frame simulated door leaf, speed determining module (optional) and electric control part;
2. Speed determining module is optional configuration, please specify before placing an order;
3. With reserved mounting holes on the simulated door leaf to assemble hinge of different specifications;
4. This Hinge Comprehensive Testing Machine adopts 7” color touch screen, PLC control;
5. Drive system adopts AC servo system, high reliability, opening and closing speed can be set;
6. Full electric drive control, no gas drive;
7. Main test items:
7.1. Repeated opening & closing operation (service life test)
7.2. Hanging load test
7.3. Opening impact test (rigid simulated wall impact test)
7.4. Closing impact test (barrier impact test)
|
AT610 Hinge Comprehensive Testing Machine |
|
|
Max. Torque |
240N.m |
|
Max. Opening angle of test door leaf |
110° |
|
Test frequency |
250~275 times/h |
|
Load cell range |
1500N |
|
Simulated door leaf (W×H×T) |
|
|
Speed sensor |
0.1~1.5m/s (optional) |
|
Power supply |
AC220V, 50Hz, 1.5kw |
