ASTM D2256 Single Yarn Strength Tester for Single Yarns With LCD Display
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Fabrics Automatic Air-jet Sample Loom for Laboratory Use
-
12inches Fabrics Automatic Rapier Sample Loom for Customized
-
Electronic Digital Crockmeter With 16mm Diameter Test Finger
-
Manual Type Crockmeter for Color Fastness
-
ASTM D4966 Martindale Abrasion and Pilling Tester With 4 Working Position
-
Fabric Pick Counter for Laboratory Use
Product Description
Product Description
HY061F Single Yarn Strength Tester is used to determine the breaking load and extension of single yarns and threads up to 500cN, 3000cN, 5000cN or 12000cN load range depending on choice of load cell.
Standard
ASTM D2256 | ISO 2062 |
GB/T3916, 14344 | BS 1932 |
Specification
Model | HY061F |
Load range | 12000cN max. (500cN, 3000cN or 5000cN optional) |
Gauge length | 250mm±1mm, 500mm±1mm |
Pre-tension range | 1cN~100cN |
Load error | ≤±1% of display value |
Elongation range | 220% max. under 250mm gauge 80% max. under 500mm gauge |
Test speed | 50mm/min~800mm/min (can be customized) |
Test times | 1~200 times settable |
Linear density | 1~999.9tex settable |
Power supply | AC220V±10%, 50Hz |
Dimensions | 550mm×450mm×1295mm |
Weight | 120kg |
Details
★ Computer control, LCD display, easy to operate
★ Large speed range, 50~800mm/min settable
★ With two gauge lengths: 250mm and 500mm
★ Automatically save data while sudden electricity failure
★ A dedicated printer can be provided to printout test data
★ The machine can also be connected with computer by using professional software
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery
Packaging | ||
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | |||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
