Help CenterModule Spare Parts 80190-580-51
Related Products
-
Module Spare Parts A402KCUS$ 1 - 100000MOQ: 1 Piece -
Module Spare Parts A4H124-24FX P0973JNUS$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts AUE-1108US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts CS-1000 UTX1700PTFEUS$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts E33NRHA-LNN-NS-00US$ 1 - 100000MOQ: 1 Piece
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| 80190-580-51 |
Diagnostic messages A diagnostics alarm is generated and the DIAG-LED flashes on the module for each diagnostics event. You can read out the diagnostics alarms, for example, in the diagnostics buffer of the CPU. You can evaluate the error codes with the user program. Note Parallel connection of two outputs For parallel connection of two outputs for redundant control of a load, the channel diagnostics "Short-circuit to L+" and "Wire break" must be deactivated. Table 5- 4 Diagnostics alarms, their meaning and corrective measures Diagnostics alarm Error code Meaning Solution Short-circuit 1H • Short-circuit of actuator supply to ground • Short-circuit of actuator supply to L+ Correct the process wiring Wire break 6H Actuator circuit impedance too high Use a different actuator type or modify the wiring, e.g. use cables with larger cross-section Wire break between the module and actuator Connect the cable Channel not connected (open) • Disable diagnostics • Connect a resistor to the actuator contacts in the load resistance range Parameter assignment error 10H • The module cannot evaluate parameters for the channel. • Incorrect parameter assignment. • Correct the parameter assignment Supply voltage missing 11H Missing or insufficient supply voltage L+ • Check supply voltage L+ on the BaseUnit • Check BaseUnit type Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Manual, 02/2019, A5E03574420-AF 23 Technical specifications 6 6.1 Technical specifications Technical specifications of the DQ 16x24VDC/0.5A ST The following table shows the technical specifications as of 02/2019. You will find a data sheet including daily updated technical specifications on the Internet (/cs/ww/en/pv/6ES7132-6BH01-0BA0/td?dl=en). Article number 6ES7132-6BH01-0BA0 General information Product type designation DQ 16x24VDC/0.5A ST, PU 1 HW functional status From FS03 Firmware version V0.0 • FW update possible No usable BaseUnits BU type A0 Color code for module-specific color identification plate CC00 Product function • I&M data Yes; I&M0 to I&M3 Engineering with • STEP 7 TIA Portal configurable/integrated as of version V14 • STEP 7 configurable/integrated as of version V5.5 SP3 • PCS 7 configurable/integrated as of version V8.1 SP1 • PROFIBUS as of GSD version/GSD revision One GSD file each, Revision 3 and 5 and higher • PROFINET as of GSD version/GSD revision GSDML V2.3 Operating mode • DQ Yes • DQ with energy-saving function No • PWM No • Oversampling No • MSO No Technical specifications 6.1 Technical specifications Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) 24 Manual, 02/2019, A5E03574420-AF Article number 6ES7132-6BH01-0BA0 Supply voltage Rated value (DC) 24 V permissible range, lower limit (DC) 19.2 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Yes Input current Current consumption, max. 60 mA; without load Output voltage Rated value (DC) 24 V Power loss Power loss, typ. 1 W Address area Address space per module • Address space per module, max. 2 byte; + 2 bytes for QI information Hardware configuration Automatic encoding Yes • Mechanical coding element Yes Selection of BaseUnit for connection variants • 1-wire connection BU type A0 • 2-wire connection BU type A0 + Potential isolation module • 3-wire connection BU type A0 + Potential isolation module • 4-wire connection BU type A0 + Potential isolation module Digital outputs Type of digital output Source output (PNP, current-sourcing) Number of digital outputs 16 Current-sinking No Current-sourcing Yes Digital outputs, parameterizable Yes Short-circuit protection Yes • Response threshold, typ. 1 A Open-circuit detection Yes Limitation of inductive shutdown voltage to Typ. L+ (-50 V) Controlling a digital input Yes Switching capacity of the outputs • with resistive load, max. 0.5 A • on lamp load, max. 5 W Load resistance range • lower limit 48 Ω • upper limit 12 kΩ
Send Inquiry to This Supplier
