Help CenterABB PFEA111-65module
Related Products
Tension measuring instruments are divided into IP20 and IP65 protection levels. They are selected according to the installation environment. The models are pfel111, pfel112 and pfel113
Pfel111: no DP interface, capable of connecting 2 indenters
Pfel112: with DP interface, capable of connecting 2 indenters
Pfel113: with DP interface, can connect 4 indenters
1. Model: pfea111
Description: the conventional control unit can connect two indenters. According to the different application environment, it has IP20 and IP65 protection levels. The PLC interface signal is 0-10V DC. Various calibration and range parameters can be set on site.
2. Model: pfcl201c
Description: pillow block tensiometer is a vertical load cell connected by cylindrical plug; Force measuring range: 5 ~ 50kN;
3. Model: pfcl201cd / CE
Description: vertical load cell of pillow block tensiometer is connected by cable sealing joint / fixed cable with protective hose, and the measuring range is 5 ~ 50kN;
4. Model: pftl101a
Description: horizontal load cell of pillow block tensiometer, connected with cylindrical plug, with force measuring range of 0.2 ~ 2Kn
5. Model: pftl101ae
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 0.2 ~ 2Kn
6. Model: pftl101aer
Description: acid resistant pillow block type tensiometer horizontal load cell, fixed cable connection, force measuring range: 0.2 ~ 2Kn It is used for measuring the tension at the wet end of paper making, and the protection grade can reach IP66 / 67
7. Model: pftl101b
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 2 ~ 20KN
8. Model: pftl101be
Description: horizontal load cell of pillow block tensiometer, fixed cable connection, force measuring range: 2 ~ 20KN
9. Model: pftl101ber
Description: acid resistant pillow block type tensiometer horizontal load cell, fixed cable connection, force measuring range: 2 ~ 20KN It is used for measuring the tension at the wet end of paper making, and the protection grade can reach IP66 / 67
10. Model: pftl201c
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 10 ~ 50kN
11. Model: pfcl301e
Description: Mini paper web tension vertical load cell, load range: 0.2 ~ 1kn
12. Model: pftl301e
Description: mini type paper web tension horizontal load cell, load range: 0.1 ~ 1kn
13. Model: pfrl101d
Description: radial load cell, rated load 5.0kn
14. Model: pfrl101c
Description: radial load cell, rated load 0.5 ~ 2.0kn
15. Model: pfrl101b
Description: radial load cell, rated load 1.0kn
16. Model: pfrl101a
Description: radial load cell, rated load 0.5kn
17. Model: pfea113
Description: tension controller, with four load cells, PROFIBUS DP field bus communication function and six configurable analog output ports.
18. Model: pfea112
Description: PROFIBUS DP field bus communication function is added on the basis of PFEA 111.
19. Model: pfea111
Description: tension controller, with two load cells, compact structure and guide rail installation.
20. Model: pftl201ce
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 10 ~ 50kN
21. Model: pftl201d
Description: horizontal load cell of pillow block type tensiometer, connected by cylindrical plug, with force measuring range of 50 ~ 100kN
22. Model: pftl201de
Description: pillow block tensiometer horizontal load cell, fixed cable connection, force measuring range: 50 ~ 100kN
23. Model: pfvl141v
Description: rectangular load cell, force measuring range: 0.63 ~ 56Mn; Width range: 70 ~ 610mm; Length range: 120 ~ 1320mm height: 74mm.
24. Model: pfvl141c
Description: circular load cell PFVL 141C, force measuring range: 1.6 ~ 60Mn; Diameter range: 210 ~ 890mm; Height: 74mm.
25. Model: pfvl141r
Description: annular load cell PFVL 141r, measuring range: 2 ~ 28mn; Outer diameter range: 240 ~ 895mm; Inner diameter range: 100 ~ 595mm height: 74mm
26. Model: pxah401
Description: millmate operator unit 400, panel mounted, can communicate with the control unit network. Size: 160 × two hundred and thirty-five ×? 60 mm, front protection grade IP65, other directions IP20, weight: 1.3 kg
27. Model: pfva401
Description: rolling force controller, which can provide excitation to load cell, with analog input / output, digital input / output, Ethernet interface, RS232 / 485 interface, optional high-speed field bus communication interface.
28. Model: pfbl141b / C
Description: the vertical force test unit is divided into single roller / double roller and fixed / rotating shaft end. The measurement range is 4 - 400 kn. The overall dimensions of pfbl 141C can be customized according to user requirements.
29. Model: pfea101
Description: constant tension closed-loop control is carried out during uncoiling and coiling. Load cells and torque output devices such as brakes, clutches and motors can be connected.
