Ruipuhua RPH Automatic N95 Mask Machine
N95 Mask Making Machine In Stock
*Technical Parameter
|
Model |
RPH-KN95 |
|
Production speed |
70-80 PCS/Minute |
|
Mask unfolded size |
(L)228mm X(W)126mm / (L)241mm X(W)128mm |
|
Non-woven fabric width |
250mm |
|
Related materials |
Non-woven fabric, filter cloth, nose clip, ear loop |
|
Mask structure |
Folding type |
|
Equipment power |
15KW |
|
Ultrasonic frequency |
20KHz |
|
Compressed air |
5-6kg/cm²,flow about 300L/min |
|
Voltage |
220V,50Hz |
|
Dimensions |
(L)8920X(W)1500X(H)2200mm |
|
Equipment weight |
Approx 2000kg |
* Equipment installation and configuration requirements
(1).Equipment size:(L)8920X(W)1500X(H)2200mm.
(2).Working power:220V±5%,50Hz,rated power:15KW.
(3).Compressed air:5-6kg/cm²,flow is about 300L/min.
(4).Use environment:temperature:10-35℃,humidity 5-35%HR,No flammable, corrosive gas, no dust (cleanness is not less than 100,000).
* Main performance characteristics
(1). Full-automatic folding mask machine, adopting PLC control system to make the material from the coil material feeding, nose clip feeding, compounding, ultrasonic welding, ear loop feeding and welding, mask folding forming, mask cutting, finished product cutting, completed at one time, the entire set of production process is automated, continuous and efficient.
(2). Intelligent control platform, man-machine interface parameter setting is convenient and fast, the operation is simple and easy to learn.
(3). High production stability, low failure rate, and small footprint.
(4). When the material of the coil and the nose clip is shortage, the photoelectric (optical fiber) detects the raw material and automatically stops to avoid waste.
(5). Automatic welding is realized by ultrasonic, accurate and stable.
(6). The ear loop cutting&welding, edge sealing mechanism and die-cutting mechanism adopt independent servo cam curve design, precise and high speed.
Company Information
RuiPuHua Machinery Equipment Co.,Ltd. established 2004, located in Foshan city, Guangdong province, It owns 60000 square meters standard workshop, Ruipuhua has always been focused on R&D design, manufacture, installation and technical services in the fields of packaging machine, automatic feeding packing line, 3 ply face mask machine and N95 face mask machine.
In recent years, Ruipuhua has successively won honorary titles such as National High-tech Enterprise, National Hidden Champion, Leading Enterprise in Subdivision Industry, Brand Enterprise, Foshan "Specialized and New" Enterprise, Foshan Quality Award First-line Team Award. In 2019, it was approved to establish the Food Processing Machinery Standards Working Group of the National Food Packaging Machinery Standardization Technical Committee to take the lead in formulating industry standards. In August 2018, Ruipuhua accepted an exclusive interview with the theme "Going to the front line to see the economy". The interview program was broadcast on the CCTV2 Financial News "Economy Half an Hour" on the evening of the 10th of that month, and on the 29th of the following month on CCTV’s "Depth Caijing's column was broadcast again, and Riphua showed to the global public how to break through and seek development in the ever-changing international environment.
