high quality coal powder ball press briquette making machine factory
- 1000 per Month
- T/T Credit Card
You May Like
-
Best sale mini small coal ash briquette machine from gold supplier
-
High briquetting ratio pellet machine briquette machines
-
High efficiency coal plant use coal dust recycle processing briquette machinery
-
Barbecue Charcoal Production Line Coal Powder Dust Briquette Ball Press Machine
-
Biomass powder briquette production plant factory sale coconut coir press machine briquette
-
High Effective Large Capacity Carbon Black Ball Briquette Press Moulding Machine
Product Description
high quality electrical coal powder ball press briquette making machine factory
The ball press machine is widely used in industries such as refractories, power plants, metallurgy, chemical industry, energy, transportation, and heating, etc. The shaped products made by coke briquette machine factory is energy-saving, environmentally friendly, easy to transport, and improves the utilization of waste materials, with good economic and social benefits. Besides, the molded materials produced by the ball pressing machine are energy-saving and environment-friendly and convenient to transport. It improves the utilization rate of waste materials, and have good economic benefits and social benefits.
Working principle of ball press machine :
This series of ball press machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Features of ball press machine:
1.The final products are smokeless, non toxic, non peculiar and environmental protection.
2.Strong and stable structure, easy, operation and maintain easily.
3.high density, high strength & high hardness because the reasonable design.
4.Final product size 25-70mm and shape can be round,pillow & square shape.
5.Roller material can be 65Mn, 9Cr2Mo, alloy Steel, high-chromium alloy and so on.
6.The final briquettes are energy saving, easy to transport and higher utilization of waste.
Main technical parameter of ball press machine:
Model | Reducer | Roller Size (mm) | Main Shaft Speed(r/min) | Matched Power(kw) | Capacity(t/h) |
XM290 | ZQ350 | 290*200 | 12-14 | 5.5 | 0.9-1.0 |
XM360 | ZQ350 | 360*250 | 12-14 | 7.5 | 1.5-2.0 |
XM400 | ZQ400 | 400*250 | 12-14 | 7.5 | 2.5-3.5 |
XM430 | ZQ400 | 430*250 | 12-14 | 11 | 3.5-4.5 |
XM500 | ZQ650 | 500*470 | 10-12 | 37 | 7.5-8.5 |
XM650 | ZQ850 | 650*470 | 9-11 | 45 | 9-10 |
XM750 | ZQ1000 | 750*570 | 9-11 | 90 | 13-14 |
XM850 | ZQ1250 | 850*570 | 8-10 | 110 | 15-17 |
