Product Description
Product Description
High capacity gravity separation jig machine for gold copper iron ore
Introduction
Jigger machine is widely used in manganese ore, Lead-zinc mine, lapis lazuli, barite ore, fluorite, pyrite, limonite, hematite,mercury and other minerals re-election.
Jigger machine is widely used in manganese ore, Lead-zinc mine, lapis lazuli, barite ore, fluorite, pyrite, limonite, hematite,mercury and other minerals re-election.
AM30 jig machine is applied to the separation operation. It has a good effect on the separate of big size raw ore and the recovery of large non-ferrous metal smelting slag.

jig machine for gold ore / jig machine for copper / Jig machine for iron


Some details
Many competitors often the thickness of the steel plate thinner, use cheaper motor, use renewable rubber, etc, to reduce the price.
Many competitors often the thickness of the steel plate thinner, use cheaper motor, use renewable rubber, etc, to reduce the price.

Area Jig different from each model Heavy mineral deposit Famous brand high quality motor

Back wash water hole Natural rubber tympanum Durable wave box
Working Principle
Jigger machine beneficiation is one way of gravity beneficiation. It belongs to deep trough separation operations, use water as processing media, it depends on the difference of specific gravity between the mine to be select and gangue to separate mine, They
are mostly in septum type, the stroke and time of stroke is adjustable depend on different specific gravity of mine, it’s widely used to select Tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other metal.
Jigger machine beneficiation is one way of gravity beneficiation. It belongs to deep trough separation operations, use water as processing media, it depends on the difference of specific gravity between the mine to be select and gangue to separate mine, They
are mostly in septum type, the stroke and time of stroke is adjustable depend on different specific gravity of mine, it’s widely used to select Tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other metal.


jig machine for gold ore / jig machine for copper / Jig machine for iron
Technical Parameters.
Model | Jig Area (M2) | Stroke (R/Min) | Feeding size (mm) | Hutch Water ( T/H) | Pressure Water (kg/cm2) | Capacity (T/H) | Power (KW) | Overall dimensions (mm) | Weight (T) |
JT0.57-1 | 0.57 | 60-160 | <6 | 1~2 | ≥0.3 | 1-2.5 | 1.5 | 1560x820x1550 | 0.612 |
JT1-1 | 1.04 | 60-160 | <10 | 2~3 | ≥0.3 | 4~10 | 2.2 | 1322x1190x1915 | 0.9 |
JT2-2 | 2.28 | 60-160 | <10 | 2~4 | ≥0.3 | 8~15 | 3 | 3225x1550x2150 | 1.637 |
JT4-2 | 4 | 50-125 | <10 | 4~8 | ≥0.1 | 8~16 | 7.5 | 4240x1990x2750 | 4.6 |
JT4-2A | 4 | 50-125 | <10 | 4~8 | ≥0.1 | 8~16 | 8 | 4240x1990x2750 | 4.6 |
JT5-2 | 4.86 | 80-120 | <10 | 4~10 | ≥0.1 | 10~20 | 7.5 | 3940x2006x2580 | 4.6 |
Company Information:About HENGCHANG

Hengchang headquarters is located in the industrial park in Gongyi City. It covers a total area of 150,000 square meters, including 100,000 square meters of standarized workshop. There are more than 200 sets of various large and medium-sized metal processing lathe, riveting machine, welding equipment and assembly equipment. We have more than 300 workers, including more than 20 middle and senior technicians. Hengchang is mainly focus on 4 series products: stone crusher machines, sand making equipment,
powder grinding mills, mineral processing equipment and their spare parts. Every year,
powder grinding mills, mineral processing equipment and their spare parts. Every year,
Hengchang can turn out 1,000 sets of crushers and 10,000 tons of crusher parts.
Customer Visit & Our Service








(A) Pre-sale services:
Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their investments.
1. Select equipment model; 2. Design and manufacture products according to clients' special requirement;
3. Train technical personnel for clients;
4. Services during the sale;
(B)Provide considerate services to minimize clients' worries:
1. Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges...
(C).After-sale services:Provide considerate services to minimize clients' worries:
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges..
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges..
Our Workshop
1.We are factory and be able to give you the lowest price than market one;
2.Our products have been exported to over 80 countries and widely used in global mining and construction industry;
3.We have a professional after-sale service team to promptly and thoroughly solve your problems; 4. Provide free process design.

Packing and delivery
Packaging Details:We will make different packaging according to different machine sizes standard international export packing,container, wooden box.
Delivery Time:We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.
Delivery Time:We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 15 to 25working days.

FAQ
Q: For providing you the suitable quotation we need to know the following information:
A:
1. What is the raw material?
2. What is the capacity per hour you required ?
3. What is the maximum input size of the raw material ?
4. What is the final briquettes size and shape you want? Once we get your answers, I can provide you the best quotation immediately.
A:
1. What is the raw material?
2. What is the capacity per hour you required ?
3. What is the maximum input size of the raw material ?
4. What is the final briquettes size and shape you want? Once we get your answers, I can provide you the best quotation immediately.
Remarks: The price will depend on different models.
Q: What about Warranty of the products ?
A:
Gongyi hengchang machinary grants our customers a twelve-month-period warranty from the date of delivery for machines exported from us. During the warranty period, in case any defect of material or workmanship occurred with spare parts in norma operation,we will at our discretion replace or repair the defective parts freely.
Q: What about Warranty of the products ?
A:
Gongyi hengchang machinary grants our customers a twelve-month-period warranty from the date of delivery for machines exported from us. During the warranty period, in case any defect of material or workmanship occurred with spare parts in norma operation,we will at our discretion replace or repair the defective parts freely.
