UK5 semi automatic Hot thermal glue spine book binder, hotmelt eva glue notebook binding machine
- 1000 per Month
- T/T Credit Card
- UT4030S eco-friendly water wash flexo polymer plate making machine, UV light photopolymer resin exposure developing equipment
- UGS31S 3 plus 1 color Automatic portable apparel clothing label flexo Printing machine, Roll to roll fabric ribbon printer
- UGS42S Automatic roll to roll fabric washable label flexo Label Printing Machine, flexographic wash care cotton ribbon printer
- UGS42S Multiple Color Automatic Fabric barcode label Flexo Printer, Garment Organza Grosgrain cotton ribbon Printing Machine
- UGS42S double side coated nylon taffeta label flexo printer, barcode woven satin ribbon flexographic printing machine
- UGS42S 4 front 2 back double side satin label flexo printer, cotton woven ribbon letterpress flexographic Printing Machine
Product Description
UK5 semi automatic Hot thermal glue spine book binder, hotmelt eva glue notebook binding machine
Video demonstration only for reference
UK5 (A4 SIZE/340MM): Video: /watch?v=Ro9Zdq1HfOE
UK7 (A3 SIZE/440MM): Video: /watch?v=lJVK7V3EFVY
Features:
1, New industrial design Heavy-duty machine frame built for long durable service life.
2, EVA Glue pre-heating decreases machine stops and inferior-quality book.
3, Adjustable cover clamp stationAccording to the thickness of book block adjust the height of cover clamp station.
4, Vertical cover clampingIt can solve the problem that the cover is easily drugged by thick book block.
5, Milling Cutters 12-tooth/20-tooth tungsten steel sun milling cutter, matched with two slotting cutters, more durable
6, Different work modeThe carriage starts from right or left end, manual mode and automatic mode available to match different binding demand.
7, Automatic side gluingAuto side gluing according to thickness of the book block, no need any adjustment and setting up.
8, Strengthened clampsBook carrier was strengthened and the clamping is more powerful, prolonging the service life.
9, Round and square book block adjust by digital displayYou can adjust the round and square book block adjust by digital display.
Parameters:
UK5 |
UK7 |
|
Max. Binding Size |
||
Binding Thickness |
60mm/2.36” |
60mm/2.36” |
Binding Speed |
200-300books/hour |
250-350books/hour |
Milling Cutters |
Sun cutter + small milling cutter |
Sun cutter + small milling cutter |
Operating Mode |
Manual, Automatic |
Manual, Automatic |
1 roller |
||
25 minutes |
25 minutes |
|
Display |
7 inch touch screen |
7 inch touch screen |
Auto Side Gluing |
Yes |
Yes |
Thickness Auto Measurement |
Yes |
Yes |
Book block and cover alignment adjust |
Yes |
Yes |
Dust Collector |
No |
Double vane dust collector motor |
Cover clamp adjust |
Yes |
Yes |
Round and Square book block adjust |
Digital display |
Digital display |
230kg |
||
Dimensions |
1000*690*1400mm |
1620*590*1400mM |
Voltage |
220/110V 50/60HZ |
220/110V 50/60HZ |
Power |
1.9KW |
2.3KW |
12-tooth sun cutter head 2 small milling cutters
Integral cast aluminum glue pot with side glue, single rubber wheel
Square corner outer band digital display
The car splint is thicker the clamping force is better.
Book block and cover alignment function makes the inside page and cover deviation adjustment convenient and quick
Clamping structure patent, vertical lifting clamping surface, plastic book molding effect is good
7-inch operating screen, intelligent operating system
Pre-sale Service After-sale Service
A: Inquiry and consulting support A: English manuel and video instruction
B: Sample testing support. B: Your technians can get trained in my factory
C: Invoice and Contract confirmation. C: Engineers available for overseas if necessary
1.Q: What information should i let you know if i want to get a quotation?
A: What is your Max and Min print size in mm?
B: Material thickness and unwinding width
C: Some photos of your finished products
2.Q: Are you a manufacturer?
A: Yes we have been manufacturing such machines over 20 years and also we are a professional exporter.
3.Q: What about the payment term?
A: Mostly 30%T/T in advanced, 60% when machine is finished after inspection and last 10% against copy of shipping documents..
4.Q: What is the warranty?
A: Two year warranty after sales (During the warranty period, we respond for free parts dispachment and the buyer is only required to cover the courier express once the machine has any problems. However we do not respond for the consumables and parts broken by mistakingly operation)
5.Q: What is your aftersale service?
A: Any questions will be responded within 24 hours by email, skype, phone call or Whatsapp/Wechat (+86-18258286679). In addtion, we have professional engineer available for overseas service..
6.Q:What is the delivery time?
A: Mostly it takes 10 to 30 workdays after receiving the deposit and confirming the drawing or samples as required.
