Food and Beverage Industry Big Cooking Pot Gas Heating Cooking Pot

          steam jacketed kettle

Product name

Jacket kettle ,jacketed kettle,  double layer kettle,

cooking pot ,layered pot, two high steamer

Industry cooking pot

Heating Source

Steam heating,   Electric heating ,   natural gas heating

Scope of application:

Food industrial,: (rice ,soup , meat, sugar, sauce, chili sauce ,tomato paste,beverage )cooking ,pasteurizing and mixing

Cosmetics industrial(lotion, bath liquid, cream paste, toothpaste, face cream , oil mixtures)

pharmaceutical products(    Herbal liquid cooking)

 other fields.  (any liquid need to be heated and mixing or no mixing)

capacity ( volume)

50L jacket kettle,  100L(Kgs)jacket kettle ,  200L(Kgs)jacket kettle ,  300L(Kgs)jacket kettle ,  400L(Kgs)jacket kettle ,  500L(Kgs)jacket kettle ,   600L(Kgs)jacket kettle ,

 1000L(Kgs)jacket kettle ,

Material

Sanitary stainless steel, ss304, ss316l,

All parts, which contact products, are applied with stainless steel

Main Advantage

gas heating cooking pot food industry cooking pot

industrial gas cooking pot big cooking pot 200litres with mixer

Jacket kettle integratesmulti-functions: such cooling, heating , pasteurizing , mixing , dispersing, emulsifying, homogenizing , in short time and very easy to operate

Generally, the machine is in simple structure, small size, light weight, low noise and running reliable.

HS code

84798200.90

Package

Plywood box, standard for exporting and protect  jacket kettle  safely deliverying

Type Jacket Kettle

Ucan50

Ucan100

Ucan200

Ucan300

Ucan400

Ucan500

Ucan600

Ucan1000

Volume (L) Kgs

50

100

200

300

400

500

600

1000

Working pressure

(Mpa)

0.09

0.30

Evaporation (Kg/h)

30

40

65

75

100

150

200

1000

Heating area (m²)

0.40

0.60

1.00

1.44

1.65

1.90

2.30

4.5

Steam Energy

consumption (Kg/h)

33

44

72

110

136

165

190

300

ID×Deep (cm)

60*45

70*52

80*55

90*63

100*68

110*75

120*78

140*82

Stirring speed (r/min)

36, 48, 62 , 200, according to customer requirement

Mixer type

Scrapper mixer or agitator no wall scrapper

Moto power (Kw)

0.37

0.37

0.55

0.75

0.75

1.1

1.1

1.5

Structure

Fixed/Inclinable/Stir

Warm Tips: volume, working pressure, motor power, electricity structure can be customized according to customer's production capacity and specific requirements.

Marks

The processing capacity is depending on different liquid, please feel free to contact our engineer by tel: +86 138 183 63408

About US/Supplier Types

1 .Trade Assurance,With Trade Assurance, you'll enjoy:

•100% product quality protection

•100% on-time shipment protection

•100% payment protection for your covered amount

2. Gold Supplier  3.   Assessed Supplier  4 . Onsite Checked  5 . A&VChecked 6.  we accept Transactions via   7. Payment protection

8 .  On-time shipment   9.  Wholesale Low MOQS

9. Popular Buying Requests for "jacket kettle" and "cooking pot"

Products big photos show:

Package details

we have general packing, standard export carton box for  jacket ketttle

Our Service

• Technical service , quick production,convenient and fast delivery, good forward with best price and good custom clearance service , whole life technical service, warranty for homogenizer pump one year

Production time

If electricity is 380V,delivery time is in one week after confirming payment

If electricity is 220V/440V, motor need to be customized, delivery time is in 15 to 18 days after payment
