500 liter electric stainless steel mixing tank used for hand sanitizer
- 1000 per Month
- T/T Credit Card
- High shear emulsification tank liquid nitrogen storage tank price used for Hand sanitizer
- 2000L Stainless steel juice mixing tank
- Industrial aseptic stainless steel electric heating double jacketed stirring tank
- Stainless Steel Mixing Tank Jacket Electric Heating tank Tank with agitator
- : 2000L juice tank steam heating tank jacketed tank
- 2000L Transport tank Storage Tank
Product Description
1000 Liter Electric Heating Mixing Tank Heated Stainless Steel Tank
Tank Specification:
- steam heating type / how water heating type / can be cooled by tap water.
- stainless steel jacket.
- made of three layer with temperature insulation.
- agitation scrapers sweeping the inner surface of the mixing tank.
- mixing capacity from 500Liter to 20,000Liter.
- or mixing capacity from 100Gallon to 5000Gallon.
- mixing speed can be 36rpm, 750rpm, or adjustable speed, the speed can be variable.
Product Advantage:
- Made of stainless steel, suitable for food and beverage production.
- Designed with jacket, allowed for hot water or steam heating, as well as tap water cooling.
- With temperature gauge <range 0~150 centigrade>.
- With glass level meter.
- CIP friendly.
Field of Application:
- Can be used as liquid storage tank, blending vessel, temporary storage tank, buffer tank and water storage tank etc.
- Ideal for food, dairy processing, fruit juice beverages, pharmaceutical, beer and wine brewing, chemical and biological engineering industries.
Construction & Configuration:
- Double wall contstruction
- The two walls make up the jacket which allowed hot water and cooling water pass through.
- Conical bottom, easy to discharge
- Sealed top, sanitary and prevent dirt in air fly in the tank effectively
- Interior welds are ground smooth, passivated and polished. Transitional areas are made into arc shaped blends to ensure no dead zones of sanitation.
- Various types of CIP cleaners.
- Vortex breaker / baffles.
- Liquid level probe and level controller (as per customer requirements.)
- Temperature probe (as per customer requirements.)
- Quick opening manway.
- Sanitary breathing cover to keep out flies and insects.
- Agitator (as per customer requirements.)
- Dismountable inlet pipe assembly.
Technical Parameters:
Working Volume (L) |
Total Height (mm) |
Diameter of Inlet & Outlet (mm) |
Motor Power (kw) |
500 | 2,450 | 38 | 0.55 |
600 | 2,550 | 38 | 0.55 |
700 | 2,550 | 38 | 0.55 |
800 | 2,700 | 38 | 0.55 |
900 | 2,700 | 38 | 0.55 |
1,000 | 2,850 | 51 | 0.75 |
1,500 | 3,050 | 51 | 0.75 |
2,000 | 3,110 | 51 | 1.1 |
3,000 | 3,700 | 51 | 1.5 |
4,000 | 3,700 | 51 | 1.5 |
5,000 | 3,950 | 51 | 2.2 |
6,000 | 4,000 | 51 | 2.2 |
7,000 | 4,250 | 51 | 2.2 |
8,000 | 4,700 | 51 | 3 |
9,0000 | 4,750 | 51 | 3 |
10,000 | 4,750 | 51 | 3 |
12,000 | 5,300 | 51 | 4 |
15,000 | 5,400 | 63 | 4 |
20,000 | 6,100 | 63 | 5.5 |
* Note:
- We also can supply customized tanks meeting your unique requirements, please feel free to contact us.
- Common rotation speed 35, 43, 60 stepless Speed reducer or Dual-speed reducer are also available.
- Insulation layer: 60mm.
- For other details, please contact us.
Shanghai Youcan Beverage Machinery Co., Ltd specializes in exporting food and beverage machineries, e.g. S.S. tank series, homogenizers, pasteurizers, tubular UHT sterilizers, CIP systems and all other SUS products from China. Over the years, we are dedicated to help customers design, manufacture, install and operate turn-key projects for their mineral water, pure water, carbonated drink, fruit juice, milk, yogurt, cheese and ice cream manufacturing needs.
Clients we serve are from Beverage, Brewing, Dairy Farm, Dairy Processing, Food, Personal Care, Pharmaceutical industries.
With our fully-experienced research and development team, we are capable of solving any technique problems concerning your production and meet all your whole-line and machinery demands. We’re ready for your inquiry and warmly welcome your contacting us.
