Food Sanitary Stainless Steel Water Purifier Storage Tank Holding Vessel Pressure Tank
Field of Application:
- Can be used as blending tank, mixing tank, preparation tank, fermentation vessel, sterilization tank and aging tank etc.
- Ideal for food, dairy processing, fruit juice beverages, pharmaceutical, beer and wine brewing, chemical and biological engineering industries.
Structure Characteristics:
- Tank body consists of internal and external shell, with insulation in between.
- Single walled tanks also available upon request.
- Fabricated from cold-rolled sanitary stainless steel (AISI 304 or 316.)
- Humanized design, easy to operate.
- Interior welds are ground smooth, passivated and polished. Transitional areas are made into arc shaped blends to ensure no dead zones of sanitation.
- Top and bottom are either conical or flat, and designed to be self-draining with no potential hold up of its contents.
Tank Configuration:
- Quick opening manway.
- Various types of CIP cleaners.
- Sanitary breathing cover to keep out flies and insects.
- Adjustable triangular legs.
- Dismountable inlet pipe assembly.
- Temperature probe (as per customer requirements.)
- Ladder (as per customer requirements.)
- Impellers available for different applications: flat blade, bar turbine, anchor, propeller three blades, axial flow four blades, axial flow three blades, double spiral, etc.;
- Jacket (Miller board, hollow jacket or coil pipe jacket are available as per customer requirements.)
- Liquid level probe and level controller (as per customer requirements.)
- Vortex breaker / baffles.
Technical Parameters:
| Working Volume (L) |
Total Height (mm) |
Diameter of Inlet & Outlet (mm) |
Motor Power (kw) |
| 500 | 2,450 | 38 | 0.55 |
| 600 | 2,550 | 38 | 0.55 |
| 700 | 2,550 | 38 | 0.55 |
| 800 | 2,700 | 38 | 0.55 |
| 900 | 2,700 | 38 | 0.55 |
| 1,000 | 2,850 | 51 | 0.75 |
| 1,500 | 3,050 | 51 | 0.75 |
| 2,000 | 3,110 | 51 | 1.1 |
| 3,000 | 3,700 | 51 | 1.5 |
| 4,000 | 3,700 | 51 | 1.5 |
| 5,000 | 3,950 | 51 | 2.2 |
| 6,000 | 4,000 | 51 | 2.2 |
| 7,000 | 4,250 | 51 | 2.2 |
| 8,000 | 4,700 | 51 | 3 |
| 9,0000 | 4,750 | 51 | 3 |
| 10,000 | 4,750 | 51 | 3 |
| 12,000 | 5,300 | 51 | 4 |
| 15,000 | 5,400 | 63 | 4 |
| 20,000 | 6,100 | 63 | 5.5 |
* Note:
- We also can supply customized tanks meeting your unique requirements, please feel free to contact us.
- Common rotation speed 35, 43, 60 stepless Speed reducer or Dual-speed reducer are also available.
- Insulation layer: 60mm.
- For other details and cutomized tanks, please contact us at WhatsApp/Cell: +86 138 1711 5848.
|
Our Company Name |
Shanghai Youcan Beverage Machinery Co., Ltd |
|
Our Industrial Experience |
More than twenty years. |
|
Machines We Manufacture & Export |
Sanitary stainless-steel made tanks, homogenizers, jacketed kettles, pasteurizers, tubular UHT sterilizers, CIP systems, bottle blowing machines, etc. |
|
Production Lines We Supply |
Mineral water, pure water, carbonated drink, fruit juice, milk, yogurt, cheese and ice cream, etc. |
|
Our Clients |
Beverage, Brewing, Dairy Farm, Dairy Processing, Food, Personal Care, Pharmaceutical industries, etc. |
|
Our Expertise |
1. With our fully-experienced research and development team, we are capable of solving any technique problems concerning your production and meet all your whole-line and machinery demands.
2. With two-decade experience in beverage machinery, we are confident to supply all machines meeting your unique requirements. |
|
Ports Our Machines Delivered |
Shanghai, Ningbo, Guangzhou, and other China main ports, and all other international destinations. |
