Bottom Entry High Speed Mixers
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
Product Description
Product Description
Tank bottom high shear emulsifier is efficient, rapid and uniform a phase or more of the phase distribution to another continuous
phase, and in the usual case each phases are mutually insoluble. Due to the rotor is generated by high speed rotation high tangent
speed and high frequency mechanical effect bring strong kinetic energy, so that immiscibility of solid phase,liquid phase and gas
phase in the corresponding mature technology and right amount under the common function of additives, the instant uniform fine
disperse emulsion, after high frequency move in circles, ultimately get the steady and high quality products.
Intermittent type high shear work process: In the high speed rotating rotor produced under the function of centrifugal force, and
the material from the work of the head and the up and down feeding area at the same time from axial suction work cavity strong
centrifugal force will material from the radial swing rotor and stator narrow gap between the precision. At the same time by
centrifugal extrusion, impact and so forth function force, make a preliminary material dispersed emulsion. After adjustment
rotating rotor outer end produce at least 15m/s more line speed, the highest can to 40m/s, and the formation of strong machine and
hydraulic force shear,liquid layer friction,impact tear, make the material full dispersing,emulsifying,uniform,crushing, at the
same time through stator slot injection. Material constant high speed from radial injection, in the material itself and the walls
of the container under the resistance change flow direction, at the same time in rotor region of the upper and lower under the
action of axial force, again form the upper and lower two strong flipping out of flow. Material after several circulation, finally
complete dispersing,emulsion,homogeneous process.
phase, and in the usual case each phases are mutually insoluble. Due to the rotor is generated by high speed rotation high tangent
speed and high frequency mechanical effect bring strong kinetic energy, so that immiscibility of solid phase,liquid phase and gas
phase in the corresponding mature technology and right amount under the common function of additives, the instant uniform fine
disperse emulsion, after high frequency move in circles, ultimately get the steady and high quality products.
Intermittent type high shear work process: In the high speed rotating rotor produced under the function of centrifugal force, and
the material from the work of the head and the up and down feeding area at the same time from axial suction work cavity strong
centrifugal force will material from the radial swing rotor and stator narrow gap between the precision. At the same time by
centrifugal extrusion, impact and so forth function force, make a preliminary material dispersed emulsion. After adjustment
rotating rotor outer end produce at least 15m/s more line speed, the highest can to 40m/s, and the formation of strong machine and
hydraulic force shear,liquid layer friction,impact tear, make the material full dispersing,emulsifying,uniform,crushing, at the
same time through stator slot injection. Material constant high speed from radial injection, in the material itself and the walls
of the container under the resistance change flow direction, at the same time in rotor region of the upper and lower under the
action of axial force, again form the upper and lower two strong flipping out of flow. Material after several circulation, finally
complete dispersing,emulsion,homogeneous process.
Product Application
Mix:syrup,shampoo,clean solution,juice concentrate,yogurt,desserts,mix milk products,printing ink.
Emulsion:medicine lotion,ointment,face mask,emulsion flavor,oil-water emulsion,emulsion asphalt,resin emulsion,wax emulsion and
pesticide.
Homogeneous:medicine lotion,ointment,face mask,tissue homogenate,dairy products homogeneous,fruit juice,printing ink and jam.
Emulsion:medicine lotion,ointment,face mask,emulsion flavor,oil-water emulsion,emulsion asphalt,resin emulsion,wax emulsion and
pesticide.
Homogeneous:medicine lotion,ointment,face mask,tissue homogenate,dairy products homogeneous,fruit juice,printing ink and jam.
Manufacturing Technique
FAQ
1 Are you manufacturer?
Yes we are the manufacturer and welcome to visit our factory
2 Can you change the machine voltage as our request
Yes we can change the machine voltage as customers’ request
3 How about your after-sale service
Our engineer can go outside to install and train your workers to operate the full machine line
4 Warranty time of your machine
2 years warranty time except for consumable spare parts
5 How about delivery time of your machine
Generally it needs 5-7 days, for big machines or producing line, it will be much longer but within our negotiated delivery time
Yes we are the manufacturer and welcome to visit our factory
2 Can you change the machine voltage as our request
Yes we can change the machine voltage as customers’ request
3 How about your after-sale service
Our engineer can go outside to install and train your workers to operate the full machine line
4 Warranty time of your machine
2 years warranty time except for consumable spare parts
5 How about delivery time of your machine
Generally it needs 5-7 days, for big machines or producing line, it will be much longer but within our negotiated delivery time
