1. Working Principles:
- First, the solid-liquid mixing materials are transported into the grinding chamber by the feed pump.
- Then the materials and grinding medium are ground by the blender in the grinding chamber, to quickly shear and grind the materials.
- At last, the finished materials are separated by the dynamic classifier, so that the finished materials are discharged from the discharge port.
2. Short Introduction:
This is a kind of high-quality Nanometer grade sand mill. The sand mill can be used to make:
(1) Printing ink: Flexo printing ink;
(2) Car paint and Industrial metal coatings: Coil coatings;
(3) Industrial anti-corrosion coatings: Woodenware paint;
(4) Screen printing ink: UV printing ink;
3. Applications:
The sand mill can be used to make Paints, printing inks, high-quality auto paints, pigments, dyes, pesticides, papermaking, sub-micron level grinding, and pharmaceutical industries.
4. Technical Parameters:
| Type | ZBW/5L |
| Grinding chamber volume | 5L |
| Adjustable grinding chamber volume | 4L |
| Main motor power | 22Kw |
| Diaphragm pump for the imported material | 1/2" |
| Zirconium beads volume | 4L |
| Spindle speed | 735r/min |
| Working pressure | < =0.1MPa |
| The maximal output pressure | 0.7MPa |
| Production capacity | 200~600 Kg/h |
| weight | 1050 kg |
| Overall dimensions (length *width * height) | 1660*850*1940mm |
(1). Our company can design the equipment according to the user's specific requirements.
(2). For the last update of the technology, we will change the technical data without notice, and the right parameters are subject to the real product.
(3). If you are not certain of which type to choose, please call us and our professional sales engineers will recommend it for you.
(4). We could give you a rapid response to your inquiry.
We could package the product according to the customer's demand.
| Packaging Detail: | wooden carton(can be customized according to user's requests and specifications) |
| Delivery Detail: | With 30 days on receiving the deposit payment |
1. Shandong Longxing Chemical Machinery Group Co., Ltd is not only the professional base for the chemical machinery but also one of the fixed companies for China National Chemical Equipment Corporation.
2. Our group has the Design License of Special Equipment in Grade D1 &D2, and the Manufacture License of Special Equipment in Grade A1 &A2.
3. We also have the Manufacture License of Special Equipment in Heat Transfer Oil Furance, ISO Quality System Certification, and CE Certification.
