Bonding Tape Self Fusing Wire Tape Tape Self Adhesive Rubber Tape

Name: Bonding Tape Self Fusing Wire Tape Tape Self Adhesive Rubber Tape
Brand: HarshMet
Price: USD $0.1 - 0.5 / Roll

FOB Price

USD $0.1 - $0.5 / Roll

10 Rolls(Min.Order)

Supply Ability 1000000 Roll / Rolls per Month
Port Xiamen, Shenzhen, Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	HarshMet	Place of Origin:	China	Model Number:	SFT-40
Material:	Other, Silicone Rubber	Type:	Insulation Tape	Application:	High Voltage
Rated Voltage:	35KV	Tensile Strength:	21N/10mm

Product Description

SFT-40C Transaprent Silicone Rubber Self Fusing Tape

Descriptions

HarshMet SFT-40 transparent silicone rubber self fusing tape is a high temperature and arc-and-track resistant tape composed of self fusing, inorganic silicone rubber and easy-tear and easy-strip liner. SFT-40 has wide
temperature tolerance of -50 to 250 . It can be
applied through 15kV for insulation and sealing for cable and reenter connections.

Sizes

Thickness* Width(mm)	Length
0.2525, 0.2530, 0.325, 0.330, 0.425, 0.430, 0.525 , 0.538.1, 0.530 , 0.545 , 0.550, 0.7525, 0.7530, 0.7538.1, 0.7545, 0.7550, 0.850, 0.5100, 0.7*100	Standard 3m, or any custom length

Features

Standard colors, black, red, yellow, green, gray, blue, orange, etc
Excellent track and arc resistance
Excellent ozone resistance
High Dielectric strength
Workable in extremely low temperatures
Excellent conformability, excellent fusion
Excellent weathering characteristics

Applications

As an ove-wrap for protection of terminating high voltage cables against arcing and tracking. Suitable for submarine cables, large motors, sensors, motors, electrical connections in aircraft engines and insulation wrap electrical equipment.

Technical Data

Performance	Typical data	Test Method
Thickness	0.51mm	ASTM D1000-76
Tensile Strength	23N/10mm	ASTM D-1000
Elongation	640%	ASTMD -1000
Dielectric Strength	35KV/mm, air	ASTM D 1000
	39KV/mm, oil
	33 KV/mm, oil at 180ºC ±5ºC	GB-T1695-2005
Fusion	Pass
UV Resistance	Pass	ASTM D 4388
Ozone Resistance	Pass	ASTM D 4388
Xenon-arc exposure@1008h	Pass	ASTM D 4388
