Home > Products > Full Heigh Turnstile Gate > Full height security turnstile/ full height rotor turnstiles/ motorised double full-height turnstile
Full height security turnstile/ full height rotor turnstiles/ motorised double full-height turnstile
- 1000 Piece / Pieces per Month
- Shenzhen, China
- T/T L/C PayPal Other
- 7 days
- Automatic full height stadium turnstile/ double lane full-height turnstile/ full height biometric turnstile gate
- Biometric full height electric turnstile/ full height singel lane turnstile/ full-height biometric turnstile
- Smart car park access barrie/ automatic rising arm barrier/ electric rising arm barrier
- Vehicle access control barrier system/ smart barrier gate/ automatic vehicle barrier
- Automatic vehicle barrier/automatic road barrier/ automatic rising traffic barrier
- Automatic car park barrier/ automatic parking barrier/ automatic arm barrier gate
Product Details
Brand Name: | Jayda | Place of Origin: | China | Model Number: | JDFHT-7 |
Product Description
Full height security turnstile, full height rotor turnstiles, motorised double full-height turnstile provide efficient crowd control solutions
Full height security turnstile JDFHT-7 is a rugged, high-reliability crowd control solution for outdoor and indoor locations, and designed to control pedestrians entering or exiting secured areas where both the high security access control and pedestrian traffic management are vital, and widely used in public security departments, bank vaults, prisons and other key security scenarios. Full height security turnstile JDFHT-7 automatically relases the arm and allow the pedestrian to push before passing through the security turnstile upon the receipt of valid signal from access control system or manual switch
Features
Shock absorption and reverse rotation locking capabilities
2. Simplified integration to access control and visitor management systems
3. Single-user, un-manned automatic access control
4. Grant fast and efficient access for authorised people
5. Automatic self-centering prevents over or under travel of rotating section
6 .Low power consumption as well as low noise operation
7. Longer turnstile life, minimal to no maintenance, higher user satisfaction
8. Easily change turnstile passage mode
9. Support automatic reset function
10. Anti-reverse rotation during transit
Applications
Public security departments
Bank vaults
Prisons
Military installations
Educational facilities
Stadiums
Parameters
Housing Material | 1.5mm~2.0mm #304 stainless sheet |
Dimension | 2400 x 1450 x 2300mm |
Power Supply | AC220V / AC110V, 50/ 60 Hz |
Channel Width | 600mm |
IP Rate | IP45 |
Pass Speed | 30 ~35 persons per minute |
Input Interface | Dry contact signal or +12V level signal or DC12V pulse signal |
Rotating Direction | Bi-directional |
Communication interface | RS485 |
Gate open when power failure | Yes |
Open Time | 0.2 second |
Life Cycle | 5 million times |
Working Temperature | -30°C~+70°C, Relative Humidity: ≤90%, no condensation |
Working Environments | Indoor, outdoor (with shelter) |
Full Height Security Turnstile Design
Full Height Security Turnstile Dimension
Full Height Security Turnstile System Diagram
Project Cases for Full Height Security Turnstile
What are full height security turnstiles?
Supplied with mechanical rotating barriers, full height security turnstiles are security access control pedestrian turnstiles that span from floor to ceiling, offering maximum security because it is impossible for an unauthorized entrant to crawl under or climb over them. Security full height turnstiles can be used for one-way or bi-directional passage depending on control requirements. When multiple lanes of entry and exit traffic are required, full height motorized turnstiles are also available–they combine two full height turnstiles into one seamless package. Full height security turnstiles provide comfortable access for handicapped entrants while still offering full floor-to-ceiling security and access control.
Full height security turnstiles variations:
Full height security turnstiles are made from heavy-gauge steel, with galvanized, powder coated, and stainless steel finishes optional. We also customizes full height gates with custom passage widths, panic bars
Full height security turnstile applications:
Full height security turnstiles are crowd control turnstiles that provide high level security and access control for handicap accessible entrances and exits. They are used to secure entrances at industrial plants, company premises and data centers. Furthermore, they are also widely used at construction sites as secure entrances through perimeter fences
What are the advantages and disadvantages of full height security turnstiles?
Full height security turnstiles provide benefits such as:
Compatibility with a guard station
Access specified through the managing party
Design allowing for unmanned or remote control
Single direction/entry and exit turnstile designs
Enhances perimeter and fence line control
Can allow for attendance monitoring
Such security turnstiles are frequently used for military installations, aquariums, amusement parks, airports, ports, stadiums, and any applications where require a secure inflow of heavy foot traffic. However, the disadvantages of the double lane full-height motorised turnstiles are the huge size and industrial appearance.
Can full height security turnstiles be integrated with 3rd party access control systems ?
Off course, full height security turnstiles are comptiable with a wide variety of access control systems by dry contact. Card pass, fingerprint / handprint reader, face recognition, barcode reader, thermal camera and token applications can integrate with such access control turnstiles.
What will happen when power off and in emergency situation?
Full height security turnstiles instantly automatically drop off their central arm for free passage under emergency situations (power outages, fire, etc)
Can full height security turnstiles be used indoor and outdoor?
Full height security turnstiles are made for indoor or outdoor situations. For all Outdoor applications, we use 304 stainless steel to prevent corrosion.
