AISI 8620 Steel Round Bar | SAE AISI 8620 Steel Round Bar Price Per Kg
US$ 0.8 - 88
MOQ: 2 Tons
Key Specifications
Get Latest Price
Brand Name:
SongShun
Place of Origin:
China
Model Number:
8620
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen,Tianjin,Shanghai.China
Delivery Detail:
10 days
Related Products
-
8620 Steel Sheet Plate | 8620 Steel Sheet Plate | AISI 8620 Steel Sheet Plate For SaleUS$ 1000 - 2585MOQ: 1 Ton -
DIN 1.6523 Steel Manufacturers | High Hardenability DIN 1.6523 Steel ManufacturersUS$ 650 - 1255MOQ: 1 Ton
-
4340 Alloy Steel Heat Resistance 4340 Steel Round BarUS$ 1000 - 1600MOQ: 1 Ton
-
4140/42CrMo/42CrMo Steel Alloy Structural Steel BarUS$ 500 - 2000MOQ: 1 Ton
-
AISI 4140 Steel Round BarUS$ 1000 - 1320MOQ: 2 Tons
Brand Name
SongShun
Place of Origin
China
Model Number
8620
Type
Alloy Steel Bar
Application
Structural Steel Bar
Technique
Hot Rolled
Standard
AISI, ASTM, BS, DIN, GB, JIS
Alloy Or Not
Is Alloy
Dimensions
custom
Special Use
Free Cutting Steel
Steel Grade
8620
8620 Steel Grade Equivalent Chart
| Country | USA | Germany/UK/France | JAPAN | ISO |
|---|---|---|---|---|
| Standard | ASTM A29/A29M-05 | EN 10084-2008 | JIS G4053-2008 | ISO 683/11:1987 |
| Grades | 8620 | 20NiCrMo2-2 (1.6523) | SNCM220 | 20NiCrMo2 |
1.6523 Steel Chemical Composition
| Stand | C (%) | Si (%) | Mn(%) | P (%) | S (%) | Cr (%) | Mo (%) | Ni (%) |
|---|---|---|---|---|---|---|---|---|
| ASTM A29/A29M-05 | 0.18-0.23 | 0.15-0.35 | 0.70-0.90 | ≤0.035 | ≤0.040 | 0.40-0.60 | 0.15-0.25 | 0.40-0.70 |
| EN 10084-2008 | 0.17-0.23 | 0.40 | 0.65-0.95 | ≤0.025 | ≤0.035 | 0.35-0.70 | 0.15-0.25 | 0.40-0.70 |
| JIS G4053-2008 | 0.17-0.23 | 0.15-0.35 | 0.60-0.90 | Max0.030 | Max0.030 | 0.40-0.60 | 0.15-0.25 | 0.40-0.70 |
| ISO 683/11:1987 | 0.17-0.23 | 0.15-0.40 | 0.65-0.95 | ≤0.035 | ≤0.035 | 0.30-0.65 | 0.15-0.25 | 0.40-0.70 |
1.6523 Steel Physical Properties
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.85 g/cm³ | 0.284 lb/in³ |
1.6523 Steel Mechanical Properties
| Mechanical Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 530 MPa | 142140 psi |
| Yield strength | 385 MPa | 113860 psi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Bulk modulus (typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80 GPa | 11600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Izod Impact | 115 J | 84.8 ft.lb |
| Hardness, Brinell | 149 | 149 |
| Hardness, Knoop (converted from Brinell hardness) | 169 | 169 |
| Hardness, Rockwell B (converted from Brinell hardness) | 80 | 80 |
| Hardness, Vickers (converted from Brinell hardness) | 155 | 155 |
| Machinability (hot rolled and cold drawn, based on 100 machinability for AISI 1212 steel) | 65 | 65 |
8620 Steel Quality Certificate & SGS Report
8620 Steel Round Bar Plate Sheet Supply Range
Round Bar
Specification: diameter: 16mm – 800mm; length: 2000mm-5000mm
Surface: Black Surface/Bright Surface/ Grinded/Peeled/Turned
Sheet/Plate/Slab
Specification: thickness: 16-800mm; width: 205mm-810mm; length: 2000mm-5000mm
Surface: Black Surface/Bright Surface/ Grinded/Peeled/Turned
