Lab Horizontal Sand Mill

   Lab Horizontal Millis an advanced wet process bead grinding machine for milling and dispersing toreduce particle size for paints, inks, pigment dispersion and other chemicals.It can achieve high milling efficiency and fine milling effect.
           Motor-driven feeding device internalhigh-speed rotation, a negative pressure, through self-absorption effect,placed above the feed tank material inhaled and sent to the grinding chamber.The discs drive the grinding medium inside the grinding chamber to do irregularmovements in all direction to put the materials under the action of constantcollision and friction. At same time, the materials are separated from thegrinding medium by the sieve and keep circulation from the tank to the grindingchamber to obtain smaller particle size, narrower particle size range.




Features:
1. High milling-efficiency and good fineness:Big kineticenergy drive zirconia working-pole to make the grinding medium move irregularly,crash with high-speed , abrase mutually etc,(Can choose diameter from 1.4mm to 1.6mm zirconia beads)
2. Convenient operation:With frequency converter,operator can start the machine and adjust working speed directly. Once poursample into the hopper of machine, with automatic cycle fuction, the millingwork can be finished automatically.
3. Low temperature-rise during milling:Both of container and millingchamber are designed with double wall for cooling sample. Normally, thetemperature-rise is less than 10℃, which effectivelyprevent sample changing because of high temperature.
4. Long lift-time:The whole machine is made up of stainless steel, moredurable and easier to clean.



Main TechnicalParameters:
1.Capacity:0.6L-5L(Containercapacity:0.6L,1.2L,2L,3L,5L for option)
2.Milling Chamber Capacity:0.5 L
3.Motor Power:2.2 KW(Siemens)
4.Working Speed:0-3000 rpm
5.Power:AC 220V,50HZ(other power canbe customized)
6.Overall Size:880mm×350mm×480mm
7.Ordering Information:JR 768----Lab Horizontal Mill
