DT-2350PA Technology Digital Tachometer Stroboscope With High Quality
Spec:
The Stroboscope is capable to provide image of single, two or multiple stillness for the vibration object, rapidly rolling object, can also use to observe the movement tracks.
Features
* Digital display gives exact reading with no guessing or errors; Wide measuring range and high resolution.
* Automatic stop flashing to save electricity and improve flash tube lifetime.
* Internal / external triggering fast conversion; x2 and ÷2 button for fast adjustment.
* Use photoelectric signal while external triggering, achieve automatic tracking function of the pattern.
* Use microcomputer technology, emerging technologies, anti-jamming technique and other advanced technology, it can measure the rotative velocity without contacting the object.
Specifications
|
Model |
DT-2350PA |
|
Display |
LCD |
|
Range |
50~12,000 FPM |
|
Resolution |
0.1 FPM(50~999.9 FPM) |
|
1 FPM(Over 1000 FPM) |
|
|
Accuracy |
±(0.05%n+1d) |
|
Sampling Time |
0.3 Seconds |
|
Internal / External Triggering Conversion |
|
|
External Trigger Level |
3~24 V |
|
H/L Range |
Flashing Light is much Brighter at |
|
Low Range than at High Range |
|
|
With x2 , ÷2 for Fast Check |
|
|
Flash Tube Life |
100 Millian Times |
|
Operating Conditions |
Temperature:0~40ºC |
|
Humidity:<85%RH |
|
|
Power Supply |
AC 220V(Optional AV 110V) |
|
Power Consumption |
About 50W |
|
Dimensions |
215x85x180 mm |
|
Weight |
Abou 1000 g |
|
Standard Accessories |
Main Unit |
|
Carrying Case(B08) |
|
|
Operation Manual |
|
|
Optional Accessories |
Sqare Flashing Tube |
|
Rechargeable Battery only for |
|
|
DT-2350PA/DT-2350PE |
|
