GE- Touch series Thermal Cycler
Product introduction:
GE- Touch uses customized Marlow(US) peltier. Its max. ramping rate is 5 ℃/s and cycle times is more than 1000,000. The product combines a variety of advanced technologies: Windows system; color touch screen; independently controlled 4 temperature zones,; PC on-line function; printing function; big storage capacity and support USB device. All above functions allow PCR’s excellent performance and meet higher experiment’s need.
Key Features
1. 8 pcs long service life Peltier heating units and form 4 circuits to control 4 temperature zones and allow double block gradient function;
2. Reinforced aluminum module with anodizing technology can keep rapid heating-conducting property and have enough corrosion resistance;
3. High heating and cooling rate, max. Ramping rate 5 ℃/s, can save your precious time;
4. Two blocks independently controlled and can run 2 different PCR programs simultaneously;
5. Stepless adjustable hot lid with pressure-protection, fit tubes of different heights to avoid tube melt and evaporation;
6. Windows interface, 8” ( 800×600, 16 colors) TFT color touch-screen with graphical display provides easy use for setting up and monitoring;
7. Built-in 11 standard program file template, can quickly edit the required files;
8. Folder management, user can build directory;
9. The running program and left time can be displayed in real time , allow to edit file when program is running;
10. One-click quick incubation function can meet experiment’s needs such as denaturation, enzyme cutting/enzyme-link and ELISA;
11. Internal flash memory for 10000 typical PCR files in free configurable folders;
12. Hot lid temperature and hot lid work mode can be set to meet different experiment’s need;
13. Automatic restart after power failure. When power is restored it can continue to run unfinished program;
14. GLP report records every step to provide accurate data support for experiment result analysis;
15. User Login Management, three-tier permission, password protection function to ensure data security;
16. Compatible with devices such as Mouse and Keyboard and capable to transfer data and perform software updates via USB Drive;
17. Support USB and LAN to update software;
18. One computer can control many sets of PCR via network connection;
19. Support email-alert function when experiment is over.
Parameters
|
Model No. |
GE9612T Gradient |
|
Capacity |
96×0.2ml |
|
Temperature Range |
0~100℃ |
|
Heating Rate |
5℃/s |
|
Cooling Rate |
4℃/s |
|
Uniformity |
≤±0.2℃ |
|
Accuracy |
≤±0.1℃ |
|
Display Resolution |
0.1℃ |
|
Temperature Control |
BlockTube |
|
Ramping Rate Adjustable |
0.1~5℃ |
|
Gradient Uniformity |
≤±0.2℃ |
|
Gradient Accuracy |
≤±0.2℃ |
|
Gradient Temp. Range |
30~100℃ |
|
Gradient Spread |
1~30℃ |
|
Hot Lid Temperature |
30~110℃ |
|
Hot Lid Height Adjustable |
Stepless Adjustable |
|
Number of Programs |
10000 +(USB FLASH) |
|
Max. No. of Step |
30 |
|
Max. No. of Cycle |
100 |
|
Time Increment/Decrement |
1 Sec ~ 600 Sec |
|
Temp. Increment/Decrement |
0.1~10.0℃ |
|
Pause Function |
Yes |
|
Auto Data Protection |
Yes |
|
Hold at 4℃ |
Forever |
|
Language |
English |
|
|
Yes |
|
LAN to computer |
Yes |
|
LCD |
8 inch,800×600 pels, |
|
Communication |
USB2.0 , LAN |
|
Dimensions |
390mm×270mm×255mm (L×W×H) |
|
Weight |
9kg |
|
Power Supply |
85~264VAC , 47~63Hz , 600 W |
More ture pictures show:
