lab tissue grinder sample grinding miller for sample preparation
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Cheap 15 to 1500rpm Ultra Thin Mini Mixer Flat Spin Magnetic Stirrer
-
CE Certification 100L -80C Freezer Water Cooled Type Water Chiller Cooling Industrial for rotary evaporator
-
Food safety fruit vegetable rapid test pesticide residue detector
-
YDS-30 Cryogenic Liquid Dewar Vessel Liquid Nitrogen Containers
-
Quality Vegetables Chicken Pet Freeze-Dried Food Freeze Dryer Machine Price
-
plant animal hair tissue grinder lab tissue grinder machine
Product Description
Specification
Mini Tissure Grinder
The laboratory site is too small, the high-throughput tissue grinder is too expensive, and it is too troublesome to bring it out for experiment. Don't worry about all these troubles. Our latest (first in the country) Mini portable grinder will solve all these problems.
Small size, only 200*160*165mm, slightly larger than a handheld centrifuge,which can be used anytime, anywhere;
Scope of application
1. Grinding and crushing samples of various plant tissues including roots, stems, leaves, flowers, fruits, seeds, etc.
2. Grinding and crushing samples of various animal tissues including brain, heart, lung, stomach, liver, intestine, lymph node, muscle, bone, skin, fat, etc.
3. Grinding and crushing of fungal samples
4. Grinding and crushing for the analysis and detection of food and pharmaceutical ingredients
5. Grinding of various tissue samples and cells before DNA, RNA, and protein extraction
Features
Advantages
1. Portable grinder with high efficiency and good effect.Finish the grinding of 1-6 samples within 1 minute;
2. No cross infection, no loss of samples
3. Easy to operate, intuitive and concise
LCD touch screen control
4. Good stability
The grinding is sufficient and the stability is better; the vibration during operation is small, and the noise is less than 60dB.
5. Good repeatability
The same procedure is set for the same tissue sample to obtain the same grinding effect; the working time is short, and the sample temperature rises small.
Details Images
Comparison before & after corn grinding
Comparison before & after Gingergrinding
Comparison before & after plant grinding
Parameters
Adapter sample-handling size | 1*2ml、3*2ml、4*2ml、6*2ml；2*5ml |
Homogenization speed | 4000 rpm |
Display method | LCD |
Mode of motion | Three-dimensional figure eight movement trajectory |
Grinding method | Wet grinding, dry grinding |
Maximum feed size | No requirement, adjust according to adapter |
Safety lock at work | Full protection |
Grinding kit material | Hard steel, PTFE (Teflon) |
Voltage | 220V to 24V DC |
Portable | It can be equipped with 24V mobile power supply (power bank) to work |
Operating hours | 0 seconds-999 seconds, 9 operating modes can be set by the user |
Grinding ball diameter | 0.1-6mm |
Grinding ball material | Alloy steel, chrome steel, zirconia, tungsten carbide, quartz sand |
Acceleration | Reach the maximum speed in 1 second |
Deceleration | Reach the minimum speed in 1 second |
Noise level | <60dB |
Dimensions | 200*160*165mm |
Weight | 2.2-3.1kg |
Power | 10-60W |
Recommendations
Packing & Delivery
Company Profile
Customer Concerns
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can you visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
1.Warranty : 1 year
2.We supply free part for quality problem in warranty
3.Long life technical support and service
